Play manufacturer video for Mars Air Systems STD296-2UG-OB Unheated Air Curtain for 96 in Door, 2 Motors, Black Powder-Coated Galvanized Steel CabinetMars Air Systems STD296-2UG-OB Unheated Air Curtain for 96 in Door, 2 Motors, Black Powder-Coated Galvanized Steel Cabinet
The Mars Air Systems STD296-2UG-OB is an unheated Standard Series 2 air curtain specified for a 96 in door. It has two 1/2 HP motors and a galvanized steel cabinet with an Obsidian Black powder coat finish.
This model uses 208–230 V, 60 Hz, 3-phase power and is rated at 1.1 kW with 3.6/3.2 A full-load amperage. Product data lists environmental separation up to 12 ft.
- 96 in overall width and nozzle length
- Adjustable air directional vanes with 40° sweep front to back
- 5-year parts warranty
Overall Dimensions:
96.0"W x 12.75"D x 12.13"HUnheated configuration
Designed as an unheated air curtain in the Standard Series 2 range.
Two-motor drive
Uses two 1/2 HP continuous-duty Totally Enclosed Air Over motors with NEMA 1 construction.
Galvanized steel cabinet
Finished in Obsidian Black powder coat.
Adjustable airflow direction
Air directional vanes provide a 40° sweep from front to back.
Environmental separation
Product data lists environmental separation up to 12 ft and insect control up to 10 ft.
AMCA performance data
The model is included in the AMCA certified lab data with 2,884 cfm volume and 85% velocity uniformity.
Parts warranty
Includes a 5-year parts warranty.
Certifications & Compliance
Warranty & Protection
5-year parts warranty.
