Garland

Garland master series 34-inch modular gas front-fired hot top range section with dual 17-inch tops

SKU: MST45T-E
$5,668.65
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best sellers Commercial ranges Garland Gas ranges New arrivals Ranges Restaurant equipment

Garland Master Series 34-Inch Modular Gas Front-Fired Hot Top Range Section with Dual 17-Inch Tops

Modular Top Only, Electric Spark Ignition, Stainless Steel Front and Sides

Built for commercial line-ups, this modular gas hot top section delivers dual 17-inch cooking zones, electric spark ignition, and flame-failure protection.

  • Modular top section with two 17-inch front-fired hot tops
  • Removable cast iron rings and lids help simplify cleanup
  • Electric spark ignition on all pilots plus Sentry flame-failure protection
  • Stainless steel front and sides for durable commercial service
  • 80,000 BTU total top output; natural gas and propane versions are listed
  • 1-1/2-inch seating flanges support modular installation
  • NSF, CE, CSA Flame, and CSA Star listed in the documentation

Overall Dimensions:

34.0"W x 31.5"D x 9.5"H

Product Weight:

305.0 lb

Dual 17-Inch Front-Fired Hot Tops

Two extra-heavy cast iron hot top sections provide a 34-inch cooking surface for high-volume service.

Modular Top Design

The T suffix denotes a modular top with 1-1/2-inch seating flanges for line-up installation.

Electric Spark Ignition

The E suffix adds electric spark ignition on all pilots for reliable startup.

Sentry Flame Failure Protection

Total flame failure protection is provided for all burners to improve operating safety.

Removable Cast Iron Ring and Lid

Rings and lids lift out for easier cleaning and day-to-day maintenance.

Stainless Steel Front and Sides

Durable stainless steel exterior surfaces help the unit stand up to busy kitchen use.

One-Piece Stainless Steel Drip Tray

A stainless steel drip tray helps catch spills and makes cleanup easier.

High-Output Gas Performance

Documentation lists 80,000 BTU total top output, with CSA-approved propane ratings shown at 60,000 BTU.

Type Hot Top Range Section
Style Front-Fired
Installation Type Drop-In
Material Stainless Steel
Finish Stainless Steel
BTU 80,000 BTU
Voltage 120 Volts
Amps 0.1 Amps
Phase 1-Phase
Plug Type NEMA 5-15P
Gas Connection Size 1-1/4 Inch NPT
Shipping Width 34 Inches
Shipping Depth 32 Inches
Shipping Height 10 Inches
Shipping Weight 305 Pounds
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Check list PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

No. The T suffix denotes the modular top version only, so this model does not include an oven.
It has two 17-inch front-fired hot tops.
It includes electric spark ignition on all pilots and Sentry total flame failure protection for all burners.
The unit uses a 1-1/4-inch NPT gas inlet. Operating pressure is 6 inches W.C. for natural gas and 10 inches W.C. for propane.
Models with the E suffix use 120 VAC single phase, 0.1 amps, with a NEMA 5-15P plug. 230 VAC 50 Hz units are direct connect.
The documentation lists 14 inches on the sides and 6 inches at the back.
