Garland Master Series 34" Heavy-Duty Even Heat Hot Top Range – Storage Base (M46S)
90,000 BTU | Natural or Propane GasBuilt to thrive in the toughest commercial kitchens, the Garland Master Series M46S pairs two extra-heavy 17" cast-iron hot tops with a spacious storage base, packing 90,000 BTU of controllable power into a compact 34" footprint.
Why chefs choose it
- Two 17" (432 mm) Even-Heat cast-iron hot tops hold and distribute heat evenly for perfect sears, browns, and slow simmers.
- Three high-performance “H” burners deliver a combined 90,000 BTU (26.37 kW) and feature individual Hi-Lo valves for precise zone control.
- Heavy-gauge aluminized steel radiation baffle system maximises heat transfer while shielding components for longer life.
- Durable stainless steel front, sides, and burner-box bottom stand up to daily cleaning and heavy use.
- 7-1/2" (191 mm) stainless steel front rail keeps pans and utensils safely within reach.
- Fully-enclosed storage base with aluminized-steel interior adds convenient, low-heat space for pans, sheet trays, or bulk ingredients.
- 6" (152 mm) chrome-plated adjustable legs make leveling and floor maintenance easy.
- Factory 1-1/4" NPT front gas connection; optional rear gas connection kit available.
Technical specifications
| Model | M46S (storage base) |
|---|---|
| Total input | 90,000 BTU/hr (26.37 kW) |
| Gas type | Natural or Propane (specify when ordering) |
| Operating pressure | Natural 6" WC (15 mbar) | Propane 10" WC (25 mbar) |
| Cooking surface | (2) 17" Even-Heat hot tops with (3) “H” burners |
| Exterior dimensions | 34" W × 38" D × 36-3/8" H (864 × 965 × 924 mm) with 6" legs |
| Clearances (combustible) |
Sides 11" (279 mm) | Back 6" (152 mm) |
| Shipping weight | Approx. 350 lb (159 kg) |
| Construction | Stainless steel front & sides, aluminized-steel storage cavity |
Popular options & accessories
- Stainless steel backguards – 10", 17", or 33" heights
- Single or double-deck tubular high shelf
- Polyurethane swivel casters with front brakes
- Rear gas connection kit (3/4" or 1" NPT) and gas flex hose with quick-disconnect
- Stainless steel main back or common front rail for line-ups (up to 102")
- End caps & covers for battery installations
Need configuration help? Call Garland Customer Service at 1-800-424-2411 or email garlandusorder@welbilt.com.
Important: This appliance is intended for commercial use only and must be installed by a qualified technician in
accordance with all local codes. Specify gas type and altitude (if above 2,000 ft / 610 m) when ordering.
$5,894.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Garland M46S Master 34" heavy-duty gas range: 90,000 BTU, two 17" even-heat hot tops, stainless steel, storage base—durable commercial performance.
Manufacturer
Garland
Brand name
Master
Height
36.38in
Width
34.0in
Depth
38.0in
Shipping Weight
350.0lbs
Base
cabinet(s)
Exterior Finish
stainless steel front & sides
Top
(2) hot tops
Specifications
Master Series Heavy Duty Range, gas, 34", (2) 17" even heat hot tops, storage base, stainless steel front & sides, 6" legs, 90,000 BTU (Garland)
