Garland M46S Master Gas Ranges
$5,894.00
Unit price
/
Unavailable
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Garland M46S Master Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Garland M46S Master Gas Ranges
$5,894.00
Unit price
/
Unavailable
Description
Garland Master Series 34" Heavy-Duty Even Heat Hot Top Range – Storage Base (M46S)
90,000 BTU | Natural or Propane GasBuilt to thrive in the toughest commercial kitchens, the Garland Master Series M46S pairs two extra-heavy 17" cast-iron hot tops with a spacious storage base, packing 90,000 BTU of controllable power into a compact 34" footprint.
Why chefs choose it
- Two 17" (432 mm) Even-Heat cast-iron hot tops hold and distribute heat evenly for perfect sears, browns, and slow simmers.
- Three high-performance “H” burners deliver a combined 90,000 BTU (26.37 kW) and feature individual Hi-Lo valves for precise zone control.
- Heavy-gauge aluminized steel radiation baffle system maximises heat transfer while shielding components for longer life.
- Durable stainless steel front, sides, and burner-box bottom stand up to daily cleaning and heavy use.
- 7-1/2" (191 mm) stainless steel front rail keeps pans and utensils safely within reach.
- Fully-enclosed storage base with aluminized-steel interior adds convenient, low-heat space for pans, sheet trays, or bulk ingredients.
- 6" (152 mm) chrome-plated adjustable legs make leveling and floor maintenance easy.
- Factory 1-1/4" NPT front gas connection; optional rear gas connection kit available.
Technical specifications
| Model | M46S (storage base) |
|---|---|
| Total input | 90,000 BTU/hr (26.37 kW) |
| Gas type | Natural or Propane (specify when ordering) |
| Operating pressure | Natural 6" WC (15 mbar) | Propane 10" WC (25 mbar) |
| Cooking surface | (2) 17" Even-Heat hot tops with (3) “H” burners |
| Exterior dimensions | 34" W × 38" D × 36-3/8" H (864 × 965 × 924 mm) with 6" legs |
| Clearances (combustible) |
Sides 11" (279 mm) | Back 6" (152 mm) |
| Shipping weight | Approx. 350 lb (159 kg) |
| Construction | Stainless steel front & sides, aluminized-steel storage cavity |
Popular options & accessories
- Stainless steel backguards – 10", 17", or 33" heights
- Single or double-deck tubular high shelf
- Polyurethane swivel casters with front brakes
- Rear gas connection kit (3/4" or 1" NPT) and gas flex hose with quick-disconnect
- Stainless steel main back or common front rail for line-ups (up to 102")
- End caps & covers for battery installations
Need configuration help? Call Garland Customer Service at 1-800-424-2411 or email garlandusorder@welbilt.com.
Important: This appliance is intended for commercial use only and must be installed by a qualified technician in
accordance with all local codes. Specify gas type and altitude (if above 2,000 ft / 610 m) when ordering.
Features & Specs
Features & Specs
Manufacturer
Garland
Brand_name
Master
Height
36.38in
Width
34.0in
Depth
38.0in
Shipping Weight
350.0lbs
Base
cabinet(s)
Exterior Finish
stainless steel front & sides
Top
(2) hot tops
Specifications
Master Series Heavy Duty Range, gas, 34", (2) 17" even heat hot tops, storage base, stainless steel front & sides, 6" legs, 90,000 BTU (Garland)
