Cleveland Range Direct Steam Kettle/Cabinet Assembly with 12-Gallon Kettle and 26-Inch Cabinet Base

Low Cabinet Height, Stainless Steel, Lift-Off Cover

This stand-mounted direct steam kettle assembly combines a 12-gallon kettle, integrated cabinet base, and built-in drain and faucet features to streamline high-volume prep.

  • One 12-gallon direct steam kettle mounted to a 26-inch wide cabinet base.
  • 304 stainless steel construction with a 316 stainless steel interior liner and #4 finish on the kettle.
  • Factory-installed steam control kit is assembled and mounted at the factory for easier setup.
  • Lift-off cover, sliding drain catch pan, and full-width drain trough simplify cleanup.
  • Hot and cold water faucet with swing spout supports filling and rinsing tasks.
  • Manual balanced tilting design helps provide controlled pouring and product transfer.

Product Weight:

160.0 lb

Stand-Mounted Direct Steam Design

Factory-assembled kettle/stand combination designed for direct steam operation in a floor-standing cabinet base.

12-Gallon Tilting Kettle

Includes one 12-gallon kettle sized for batch cooking, holding, and serving applications.

304 Stainless Steel Construction

Durable stainless steel construction is used throughout the stand-mounted assembly for commercial use.

316 Stainless Steel Interior Liner

The kettle interior uses a 316 stainless steel liner for added corrosion resistance.

Lift-Off Cover

Removable cover helps with loading, cleaning, and daily access.

Factory Installed Steam Control Kit

Includes a needle type steam control valve, steam trap, condensate strainer, check valve, nipples, and fittings, factory assembled and mounted.

Full-Width Drain Trough and Sliding Drain Pan

A full-width drain trough with sliding catch pan and splash shield helps manage cleanup and drips.

Double Pantry Faucet

Hot and cold water faucet with swing spout provides convenient water access for prep and cleanup.

Manual Balanced Tilting

Balanced manual tilt design supports controlled pouring and transfer.

50 PSI Steam Jacket Rating

Kettle jacket is rated to 50 psi and operates from a 5 to 45 psi steam supply.

Type Direct Steam Kettle/Cabinet Assembly
Style Stand Mounted
Installation Type Floor Model
Capacity 12 Gallons
Material 304 Stainless Steel
Interior Finish 316 Stainless Steel
Finish #4 Finish
Controls Manual
Connection Size 1/2 Inch IPS Minimum Line
Water Inlet Size 3/4 Inch O.D. Copper Tube or 1/2 Inch NPT Pipe
Drain Connection Size 1 1/2 Inch Diameter Straight Pipe Thread
Water Connection Required
Drain Connection Required
Selling Unit Each
Units Per Case 1
Shipping Width 45 Inches
Shipping Depth 44 Inches
Shipping Height 55 Inches
Shipping Weight 240 Pounds

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It connects directly to a steam source supplying 5 to 45 psi, and the steam jacket is rated at 50 psi.
This model includes one 12-gallon (45-liter) kettle.
Water requires 3/4" O.D. copper tube or 1/2" NPT pipe, and the drain uses a 1 1/2" diameter straight pipe thread connection.
The unit includes a lift-off cover, sliding drain catch pan with splash shield, and a full-width drain trough.
Available options include a cooking basket, food strainer, steam pressure reducing valve, steam supply moisture separator/trap, single pantry faucet, wall meter, wall-mounted water cooling, back wall or back splash, and a self-locking hand tilt mechanism for 12-gallon models.
