Cleveland Range 24GMK6200 Steam Kettles
Cleveland Range 24GMK6200 Steam Kettles is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Cleveland Range 24GMK6200 Steam Kettles
Description
Cleveland 24-GM-K6-200 Gas Kettle & Cabinet Assembly
6-Gallon 2/3-Jacketed Kettle • 24" NickelGuard™ Modular Base • 200,000 BTU Steam BoilerBuilt for busy commercial kitchens that demand speed, consistency, and rock-solid durability, the Cleveland 24-GM-K6-200 combines a high-efficiency gas boiler with a 6-gallon stainless steel kettle—all in a compact 24" footprint. From delicate sauces to hearty soups, you’ll turn out up to 160 four-ounce servings per batch while saving labor, energy, and floor space.
Performance & Convenience Features
- 200,000 BTU NickelGuard™ boiler delivers rapid, reliable steam with built-in corrosion resistance.
- 2/3 jacketed, 6-gal kettle in type 304 stainless—fast, even heating without hot spots.
- Manual tilt, balanced design for safer, smoother pouring; handle mounts on either side.
- Lift-off cover helps hold heat and reduce evaporation.
- Double pantry faucet (hot & cold) with swing spout for quick water fills.
- Integrated sink, drain & splash guard keep the work zone clean and efficient.
- Solid-state water-level controls, low-water cut-off, pressure limit control & 15 psi safety valve.
- Electronic spark ignition with illuminated Start/Reset switch—no standing pilot means energy savings.
- All major components are serviceable from the front to minimize downtime.
- Adjustable stainless flanged feet level the unit on uneven floors.
- Engineered to meet UL, NSF #4 and CSA standards.
At-a-Glance Specifications
| Model | 24-GM-K6-200 |
|---|---|
| Kettle Capacity | 6 gal / 23 L (≈ 160 × 4 oz servings) |
| Number of Kettles | 1 |
| Cabinet Width | 24" / 600 mm (standard height) |
| Boiler Output | 200,000 BTU/h, gas-fired |
| Kettle Jacket Rating | 50 psi |
| Boiler Operating Pressure | 15 psi safety valve |
| Electrical (controls) | 115 V, 60 Hz, 1-phase |
| Gas Type | Natural (other gases available, consult factory) |
| Construction | 304 SS kettle, 430 SS cabinet & tabletop with 1.5" drain trough |
| Included Accessories | Lift-off lid, double pantry faucet, sink & drain, splash guard |
| Warranty | 1-year parts & labor + 4-year prorated boiler parts |
NickelGuard™ Advantage
- Nickel-enriched boiler interior resists corrosion from treated or hard water.
- Automatic blow-down on shutdown extends boiler life and simplifies maintenance.
- Factory start-up (with free water-quality check) available at no additional charge.
Need a larger system or 316 SS kettle for acidic products? Ask our team about additional Cleveland Range options and accessories.
