Description
6-Gallon Direct-Steam Tilting Kettle on 18" Cabinet Base
Cleveland Range – Model SD-450-K6Get true steam-powered performance in the smallest possible footprint. Cleveland’s SD-450-K6 combines a 6-gallon 2/3-jacketed kettle with a low-profile, 18-inch-wide stainless cabinet, complete drain system, faucet and factory-plumbed steam controls—arriving ready to connect to any 5-45 psi direct-steam line.
Key features
- 6-gallon (23 L) capacity cooks ≈160 × 4 oz portions per batch.
- 2/3 steam jacket surrounds food for even heating with no hot spots.
- 316 stainless steel liner handles acidic foods better than 304 SS.
- Manual, balanced tilt—smooth, controlled pouring with no gears or hydraulics.
- Low 18" (457 mm) cabinet height keeps the pour lip at a comfortable working level.
- Factory-installed Steam Control Kit (needle valve, trap, strainer, check valve & fittings).
- Full-width drain trough with 1 ½" male outlet plus sliding catch pan & splash shield.
- Double pantry faucet (separate hot & cold) with swing spout for filling and clean-up.
- Lift-off stainless cover speeds heat-up and minimizes energy loss.
- 50 psi jacket rating, chrome-plated safety valve; NSF & ASME listed.
Capacities
| Usable volume | 6 gal / 23 L |
|---|---|
| Portions (4 oz) | ≈160 per batch |
Utility connections
| Steam inlet | ¾" IPS, 5–45 psi clean, dry steam |
|---|---|
| Water (faucet) | ½" O.D. copper tube or ½" NPT |
| Drain | 1 ½" male standard pipe thread |
| Clearances | Right 0" • Left 0" • Rear 0" |
Shipping data
| Crated weight | 145 lb (66 kg) |
|---|---|
| Crated size (W × D × H) | 45" × 44" × 55" |
Included & optional accessories
- Included: Lift-off cover, double pantry faucet, sliding drain pan with splash shield, complete steam control kit.
- Optional: Cooking baskets, food strainer, PRV (for steam > 45 psi), moisture separator, gallonage meter, back splash panel & more.
Standard warranty: 1-year parts & labor plus 4-year prorated pressure vessel coverage.
Factory-authorized start-up and extended warranty packages are available.
Important: Connect only to clean, dry steam within the specified pressure range and follow local codes.
Poor water quality, excessive steam pressure or improper installation can void the warranty.
Features & Specs
Features & Specs
Manufacturer
Cleveland Range
Shipping Weight
140.0lbs
Kettles
(1) 6 gallon
Base
18" wide cabinet
Kettle Liner
stainless steel
Specifications
Kettle/Cabinet Assembly, direct-steam, 18" W cabinet base, with one 6-gallon kettle, low cabinet height, stainless steel kettle, top, front & sides, lift-off cover, double pantry faucet, sliding drain pan with splash shield, 316 stainless steel liner, factory installed steam control kit
