Cleveland Range 36DMK1010 Steam Kettles
Cleveland Range 36DMK1010 Steam Kettles is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Description
Cleveland 36-DM-K1010 Direct-Steam Modular Kettle Station
36" cabinet base • (2) 10 gal 2/3-jacketed kettles • Manual tiltBoost batch cooking throughput without giving up floor space. The Cleveland 36-DM-K1010 pairs two 10-gallon steam-jacketed kettles with a rugged 36" stainless cabinet base—factory-assembled, plumbed, and ready to connect to your in-house steam supply. From silky soups to high-acid tomato sauces, the 316 stainless kettle liners protect flavor and simplify cleanup while manual tilting and a built-in swing faucet keep production moving.
Key advantages
- 20 gal total capacity (320 × 4 oz servings per kettle) in a 36" footprint
- Direct-steam design heats product up to 30% faster than electric models
- 2/3 steam jacket delivers even, wrap-around heat with no hot spots
- Manual tilt with balanced trunnions for smooth, controlled pouring
- Steam Control Kit factory-mounted: needle valves, trap, condensate strainer, check valve, nipples & fittings
- 316 series stainless kettle liners resist pitting & corrosion from acidic foods
- Type 430 stainless exterior and tabletop with 1½" drain trough
- Lift-off covers hold in heat yet remove instantly for stirring or cleaning
- Double pantry (hot & cold) swing faucet fills kettles without carrying stock pots
- Adjustable flanged feet bolt to floor for a rock-solid installation
- 50 psi jacket rating with chrome-plated safety valves for peace of mind
- Tilt handles can be mounted on either kettle side for line-flow flexibility
Specifications
| Model | 36-DM-K1010 |
|---|---|
| Base width | 36 in / 900 mm |
| Capacity | (2) × 10 gal (36 L) kettles • 20 gal total |
| Jacket type | 2/3 steam jacket, direct connection to 5–10 psi steam supply |
| Jacket rating | 50 psi (345 kPa) with safety valve |
| Construction | Type 430 stainless exterior cabinet & tabletop; 316 stainless kettle liner |
| Tilting mechanism | Manual hand-tilt, balanced design |
| Faucet | Hot & cold swing spout (double-pantry style) |
| Drain trough | 1 ½" Ø male drain fitting, centered in tabletop |
| Steam control kit | Needle valve, steam trap, condensate strainer, check valve, nipples & fittings (factory-mounted) |
| Feet | Adjustable flanged floor-mount feet |
| Warranty | 1-year parts & labor standard; additional prorated boiler coverage per Cleveland policy |
Utility connections
- Steam: ¾" IPS, 5–10 psi operating pressure
- Water: ½" NPT hot & cold
- Drain: 1 ½" IPS common drain (do not use PVC)
UL/NSF certified. Designed and assembled in the USA.
