Cornelius 631100050 Post-Mix Soda Dispenser, Drop-In Ice-Cooled, 8 Lever Valves, 80 lb Ice Capacity, Stainless Steel Exterior
SKU: 631100050
$8,412.02
The Cornelius 631100050 CB2323 is a drop-in, ice-cooled post-mix soda dispenser with eight UFB-1 sanitary lever valves and an 80 lb ice capacity.
- Valve configuration: Six chilled syrup positions and two ambient syrup positions.
- Installation: Requires a 23-1/4 in. x 23-1/4 in. counter cutout.
- Construction: All stainless steel exterior with a stainless steel tower and no merchandiser.
- Electrical: 120 V, 60 Hz, single-phase, 1.0 A.
Overall Dimensions:
23.0"W x 23.0"D x 33.0"HProduct Weight:
225.0 lbEight UFB-1 lever valves
Uses eight sanitary UFB-1 post-mix lever valves with a 2-4 oz. serving format.
Ice-cooled drop-in design
Designed for drop-in installation with an ice-cooled dispenser format.
80 lb ice capacity
The ice chest provides an 80 lb ice capacity.
6-2 carb/non-carb manifold
Configured for six chilled syrups and two ambient syrups.
Stainless steel construction
Features an all stainless steel exterior and stainless steel tower without a merchandiser.
Built-in drip tray
Includes a built-in drip tray.
Countertop fit
Requires a 23-1/4 in. x 23-1/4 in. counter cutout and provides 9-3/4 in. cup clearance.
Product Type
Post-mix soda beverage dispenser
Installation
Drop-in
Cooling
Ice-cooled
Valve Type
UFB-1 sanitary lever
Number of Valves
8
Ice Capacity
80 lb
Manifold
6-2 carb/non-carb; 6 chilled syrups and 2 ambient syrups
Cup Clearance
9-3/4 in.
Counter Cutout
23-1/4 in. x 23-1/4 in.
Electrical Requirements
120 V / 60 Hz / 1 ph; 1.0 A
Exterior Finish
All stainless steel exterior
Merchandiser
None
Drip Tray
Built-in
Weight
225 lb
Certifications & Compliance
Frequently Asked Questions
It has eight UFB-1 sanitary lever valves.
The ice capacity is 80 lb.
A 23-1/4 in. x 23-1/4 in. counter cutout is required.
It requires 120 V, 60 Hz, single-phase electrical service at 1.0 A.
