Key specifications

Amps
14.4 Amps at 208 Volts; 16.6 Amps at 240 Volts
Phase
1-Phase
Dimensions
50.0"W × 30.0"D × 36.0"H
Type
Hot Food Counter
Style
Enclosed Base
Installation Type
Floor Model
Spec sheet

Piper Products/Servolift Eastern Reflections R3-HF Mobile 3-Well Hot Unit

$7,723.50
/each
Estimated to ship in 41–44 business days

Made to order. Lead times are estimates and can change with the factory’s production schedule. You can cancel free within 24 hours of ordering if production hasn’t started. Once it starts, canceling may not be possible or may carry the manufacturer’s cancellation fee.

Wells
ElectricalRequired
Drain
Protector guard
Factory Add-Ons
Electrical accessories

Need something else? Contact us.

Included: Piper Products/Servolift Eastern warranty One-year parts and labor warranty

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $714/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Specifications

Type Hot Food Counter
Style Enclosed Base
Installation Type Floor Model
Material Fiberglass Reinforced Plastic
Top Material Stainless Steel
Body Construction Molded F.R.P.
Pan Capacity 3 Pans
Pan Size 12 x 20 Inches
Well Type Sealed Well
Drain Type Manifold Drains
Mobility Mobile
Caster Type Swivel Plate Casters with Brakes
Voltage 208/240 Volts
Watts 3,000 Watts at 208 Volts; 3,990 Watts at 240 Volts
Amps 14.4 Amps at 208 Volts; 16.6 Amps at 240 Volts
Phase 1-Phase
Plug Type NEMA 6-30P
Cord Length 7 Feet
Heating Element 1,000 Watts at 208 Volts; 1,330 Watts at 240 Volts per Well

Description

Mobile hot food service: The Reflections R3-HF is an electric serving counter with three sealed 12 x 20 inch wells, a stainless steel top, and an enclosed base.

  • Molded F.R.P. body with rounded corners
  • 14-gauge stainless steel top with fully welded square turndowns
  • Wells can operate wet or dry
  • Manifold drains are standard
  • Heating elements are accessible without removing the unit top
  • Four-inch swivel plate casters with brakes support mobile use

The unit measures 50 inches wide by 30 inches deep by 36 inches high and uses a 208- or 240-volt, single-phase electrical configuration.

Overall Dimensions:

50.0"W x 30.0"D x 36.0"H

Product Weight:

270.0 lb

Three sealed wells

Includes three 12 x 20 inch sealed wells for pans up to 6 inches deep.

Stainless steel top

Features a 14-gauge stainless steel top with fully welded square turndowns on all sides.

Molded F.R.P. body

The body has a smooth exterior and rounded corners.

Wet or dry operation

The wells can be run wet or dry.

Works-in-a-drawer element access

Heating elements can be accessed without removing the unit top.

Mobile base

Includes four-inch diameter swivel plate casters with brakes.

Manifold drains

Manifold drains are standard.

Modular interlocking

An interlocking mechanism is provided for connection with other Reflections units.

Frequently Asked Questions

It has three sealed 12 x 20 inch wells.
The counter measures 50 inches wide by 30 inches deep by 36 inches high.
It is available in 208 or 240 volts, single phase, with a NEMA 6-30P plug.
Yes. The wells can be run wet or dry.
Yes. The R3-HF has an enclosed base.
The product has a one-year, or 12-month, parts and labor warranty subject to Piper's warranty terms.

This ships by freight truck on a pallet, not by a parcel carrier. The carrier calls ahead to set a delivery window, and an adult 18 or older must be there to receive, inspect and sign for it.

The driver brings it to the back of the truck, or lowers it to the ground with liftgate service. They don’t bring it inside, so plan for a pallet jack or two people to move it from the curb.
