Hoshizaki KM-520MRJZ Slim-Line Modular Remote Air-Cooled Crescent Cube Ice Maker, 22 Inch Wide

SKU: KM-520MRJZ
$4,710.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Ice Makers Hoshizaki Ice Machines Ice Makers & Bins New Arrivals Restaurant Equipment

Hoshizaki KM-520MRJZ Slim-Line Modular Remote Air-Cooled Crescent Cube Ice Maker, 22 Inch Wide

Up to 547 lb/Day, 115V, Remote Condenser Sold Separately

This compact 22-inch-wide modular ice maker delivers high-volume crescent cube production while keeping heat and noise away from the kitchen with a separate remote condenser.

  • Up to 547 lb of crescent cube ice per 24 hours at 70°F/50°F; 495 lb AHRI certified at 90°F/70°F.
  • Remote air-cooled design uses a separately priced condenser.
  • Slim 22-inch-wide footprint suits space-conscious installations.
  • ENERGY STAR recognized for efficient operation.
  • CleanAssist, self-diagnostics, CycleSaver, and EverCheck simplify maintenance and operation.
  • Hard-wired 115V operation with a stainless steel double-sided evaporator.

Overall Dimensions:

22.0"W x 27.38"D x 28.0"H

Product Weight:

175.0 lb

Remote Condenser Operation

Designed for a separate remote condenser sold separately to keep heat and noise away from the ice machine location.

Crescent Cube Ice

Produces individual crescent-shaped cubes.

High Production Output

Makes up to 547 lb per 24 hours at 70°F/50°F.

Factory-Installed Ultrasonic Bin Control

Adjustable on site to help manage bin levels.

CleanAssist One-Hour Cleaning

Simplifies routine cleaning and maintenance.

Self-Diagnostic Programming

Automatically adjusts to changing conditions for dependable performance.

CycleSaver and EverCheck

Supports efficient cycling and provides service alerts.

Stainless Steel Double-Sided Evaporator

Durable construction supports long-term use and easier cleanup.

Hard-Wired Installation

Power cord is not included; the unit must be hard-wired at the site.

Type Ice Maker
Style Slim-Line Modular
Ice Type Crescent Cubes
Refrigeration Type Remote
Condenser Type Air-Cooled
Production Capacity 547 lb per 24 hours
Refrigerant Type R-404A
Voltage 115 Volts
Amps 12.05 Amps
Hertz 60 Hz
Phase 1-Phase
Breaker Size 20 Amps
Plug Type Hardwired
Water Connection Required
Drain Connection Required
Water Inlet Size 1/2 Inch FPT
Drain Connection Size 3/4 Inch FPT
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of Energy Star Certified
Energy Star Certified
Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Warranty & Protection

3-year parts and labor on the entire machine; 5-year parts and labor on the evaporator; 5-year parts on the compressor and air-cooled condenser coil.

Documents

PDF Cutsheet PDF Download PDF Kmedge cuber flyer PDF Download PDF Cleaning sheets PDF Download PDF Ice machine brochure PDF Download PDF Ice maker calculator PDF Download

Frequently Asked Questions

No. The remote condenser is priced separately, and the document notes that Z-model ice machines should be paired with a Z-model remote condenser.
URC-5FZ is listed as the remote condenser to use with KM-520MRJZ.
The document lists 25' HS-5587 and 35' HS-5588 brazed line sets as sold separately.
Up to 547 lb per 24 hours at 70°F/50°F, with 495 lb AHRI certified at 90°F/70°F.
It requires 115V/60/1-phase power, draws 12.05 amps, uses a 20A max fuse/circuit, and must be hard-wired. The power cord is not included.
Allow 6 inches at the rear, sides, and top for proper air circulation and maintenance access.
