Duke Manufacturing

Thurmaduke G-3-DLPG 3-Well Deluxe Gas Dry Heat Steamtable Unit

SKU: G-3-DLPG
$6,325.83
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Steam Table Duke Manufacturing Food Bars & Buffets Food Wells & Serving Lines New Arrivals Restaurant Equipment Serving & Display Equipment Serving Counters

Thurmaduke G-3-DLPG 3-Well Deluxe Gas Dry Heat Steamtable Unit

46-Inch, Full-Size Pan Capacity, Propane Gas, Enclosed Base

The Thurmaduke G-3-DLPG deluxe gas steamtable provides reliable dry heat for holding three full-size pans, ensuring your hot food remains at optimal serving temperatures.

  • Equipped with three 12" x 20" dry heat wells for versatile food holding.
  • Features a durable one-piece, 16 gauge 300 series stainless steel top for longevity and easy cleaning.
  • Individual burners and adjustable gas valves allow for precise temperature control per well.
  • Convenient integral stainless steel cutting board and a heavy-gauge dish shelf are included.
  • Constructed with a robust 20 gauge paint grip steel body and 6" adjustable stainless steel legs.
  • Designed to operate efficiently on Propane Gas with a total output of 7,500 BTU.

Overall Dimensions:

46.0"W x 34.0"D x 36.0"H

Product Weight:

335.0 lb

Durable Stainless Steel Top

One-piece, 16 gauge, 300 series stainless steel top provides a robust and hygienic work surface with die-stamped 12" x 20" openings.

Individual Dry Heat Wells

Each of the three wells features an individual burner, adjustable gas valve, galvanized steel radiation plate, and safety pilot for independent and precise temperature control.

Integrated Food Preparation Area

An integral stainless steel cutting board offers a convenient space for food preparation or carving directly on the unit.

Built-in Dish Shelf

A heavy-gauge, one-piece stainless steel dish shelf, 8 1/2" wide, provides a practical area for plates and serving dishes, also housing control knobs with wire guards.

Sturdy Construction

The body and undershelf are made from 20 gauge paint grip steel, ensuring durability, while 6" polished stainless steel adjustable legs provide stability.

Safety Features

Equipped with safety pilots for each burner and a gas pressure regulator for the unit to ensure safe operation.

Type Commercial Steam Table
Style Hot Food Unit
Installation Type Floor Model (With Legs)
Pan Capacity 3 Full-Size Pans
Compartments 3
Cooking Surface Width 12 Inches (per opening)
Cooking Surface Depth 20 Inches (per opening)
BTU 7,500 BTU
Gas Type Propane
Gas Connection Size 1/2" I.P.S.
Gas Inlet Pressure Null
Controls Individual Gas Valves, Safety Pilots
Material 16 Gauge Stainless Steel Top, 20 Gauge Paint Grip Steel Body
Interior Finish Stainless Steel
Finish Painted
Color Null
Shipping Width 46 Inches
Shipping Depth 34 Inches
Shipping Height 36 Inches
Shipping Weight 335 lb.
Selling Unit Each
Units Per Case 1
Country of Origin USA

Certifications & Compliance

Certified badge of UL Certified
UL Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1-year limited warranty on parts and labor

Documents

PDF Cutsheet PDF Download PDF Color chart PDF Download PDF Owner's manual PDF Download PDF Warranty PDF Download

Frequently Asked Questions

The G-3-DLPG model is designed to operate on Propane Gas. However, the Thurmaduke Deluxe Gas series can be ordered for either natural gas or propane gas.
This unit is designed with three 12" x 20" top openings, allowing it to accommodate three full-size food pans.
Yes, each of the three heat compartments has its own individual burner and adjustable gas valve, providing independent temperature control for each well.
The G-3-DLPG model has a total BTU output of 7,500 BTU, with each burner rated at 2,500 BTU/hour.
Yes, the unit features an integral stainless steel cutting/work surface built into the top.
The product comes with a one-year limited warranty covering parts and labor, commencing from the date of installation or six months from the factory shipment date, whichever is sooner. This warranty applies to products used within the United States, Canada, and Mexico.
