Atlas Metal

Atlas Metal MOPD4H-9-1/8 Mobile Heated 4-Stack Plate Dispenser for up to 9 1/8" Dishes

SKU: MOPD4H-9-1/8
$7,436.45
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Atlas Metal Best Sellers Commercial Carts Dish & Tray Dispensers Dish Caddy & Dispenser Food Holding & Warming Equipment New Arrivals Storage & Transport

Atlas Metal MOPD4H-9-1/8 Mobile Heated 4-Stack Plate Dispenser for up to 9 1/8" Dishes

Heated, Mobile, Open Frame, 4-Compartment

Efficiently store and serve a large volume of hot plates with this robust and mobile heated plate dispenser.

  • Maintains serving temperature for up to 288 plates across 4 heated, self-leveling tubes.
  • Accommodates round dishes up to 9 1/8 inches in diameter.
  • Durable all stainless steel construction for commercial kitchen demands.
  • Mobile open frame design with 4-inch swivel casters allows for easy transport.
  • Field-adjustable spring mechanism adapts to different plate weights.
  • UL Listed and NSF Approved for safety and sanitation standards.

Overall Dimensions:

30.38"W x 30.38"D x 36.0"H

Product Weight:

188.0 lb

Mobile Open Frame Design

Constructed with 1" stainless steel tubing, welded to a 16 gauge stainless steel upper and lower deck with heavy-duty reinforcements for durability and easy mobility.

Mobile Open Frame Design

Heated Self-Leveling Dispensing Tubes

Four individual tubes, each made of 300 series stainless steel, with a base-mounted heating element, side-mounted thermostat, pilot light, and on-off switch to maintain optimal serving temperatures.

Adjustable Spring Mechanism

Features extension springs that are easy to adjust in the field to accommodate various plate weights and desired dispensing heights.

High-Impact Plastic Guide Posts

Three guide posts per tube ensure proper alignment of plates, reducing chips and spills.

Generous Capacity

Each tube holds up to 72 plates or 36 bowls, providing a total capacity of up to 288 plates or 144 bowls for high-volume service.

Heavy-Duty Swivel Casters

Equipped with four 4-inch swivel casters for smooth and convenient transportation within your facility.

Integrated Cordset

A 6-foot, 120V NEMA 5-15P cord set is included for immediate electrical connection.

Type Plate Dispenser
Style Mobile Open Frame
Installation Type Floor Model (With Casters)
Compartments 4
Plate Diameter 9 1/8 Inches
Plate Style Round
Capacity Up to 288 plates or 144 bowls (72 plates or 36 bowls per tube)
Material Stainless Steel
Voltage 120 Volts
Amps 12.7 Amps
Watts 1520 Watts
Hertz 60 Hz
Plug Type NEMA 5-15P
Cord Length 6 Feet
Shipping Width 31 Inches
Shipping Depth 31 Inches
Shipping Height 36 Inches
Shipping Weight 188 lb.
Selling Unit Each
Units Per Case 1
Country of Origin USA

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

This dispenser is designed to accommodate round dishes with a maximum diameter of 9 1/8 inches.
Each self-elevating dispensing tube has a capacity for up to 72 plates or 36 bowls.
Yes, this is a heated model (MOPD4H), featuring a base-mounted heating element, thermostat, pilot light, and on-off switch for each tube to keep plates warm.
Yes, the spring mechanism is field-adjustable, allowing you to fine-tune the dispensing height for various plate weights.
The unit operates on 120 Volts, drawing 12.7 Amps and consuming 1520 Watts. It comes with a 6-foot cordset and a NEMA 5-15P plug.
Yes, it features a mobile open frame design equipped with four 4-inch heavy-duty swivel casters for easy transport.
