Atlas Metal MOPD4-10-1/8 Mobile Open Plate Dispenser, 4-Stack, Unheated, 10 1/8" Max Dish Diameter

SKU: MOPD4-10-1/8
$5,205.92
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Atlas Metal Best Sellers Commercial Carts Dish & Tray Dispensers Dish Caddy & Dispenser Food Holding & Warming Equipment New Arrivals Storage & Transport

Atlas Metal MOPD4-10-1/8 Mobile Open Plate Dispenser, 4-Stack, Unheated, 10 1/8" Max Dish Diameter

Full-Size, Open Frame, Mobile, Unheated

Efficiently organize and transport a large quantity of plates with this durable and versatile 4-stack mobile plate dispenser.

  • Heavy-duty stainless steel construction ensures long-lasting durability in commercial environments.
  • Features four self-elevating dispensing tubes for easy plate access.
  • Each tube holds up to 72 plates or 36 bowls, maximizing capacity.
  • Designed for plates up to 10 1/8 inches in diameter.
  • Mobile open frame design with 4-inch swivel casters allows for easy movement.
  • Spring mechanism is field adjustable to accommodate various plate weights and maintain proper dispensing height.

Overall Dimensions:

30.38"W x 30.38"D x 36.0"H

Product Weight:

188.0 lb

All Stainless Steel Construction

The frame is constructed of 1-inch stainless steel tubing, welded to a 16 gauge stainless steel upper and lower deck with heavy-duty reinforcements. Dispensing tubes are made of 300 series stainless steel.

All Stainless Steel Construction

Four Self-Elevating Dispensing Tubes

Each unit is equipped with four independent tubes that automatically adjust to the plate stack height for convenient access.

High-Impact Plastic Guideposts

Three guideposts on the counter top flange help align plates within the dispensing tubes, ensuring smooth operation.

Field Adjustable Spring Mechanism

The extension spring mechanism is easy to adjust to accommodate different plate weights, maintaining the desired dispensing height.

High Capacity

Each dispensing tube has a capacity of up to 72 plates or 36 bowls, allowing for efficient plate storage and serving.

Mobile Design

Equipped with 4-inch heavy-duty swivel casters for effortless portability throughout your foodservice operation.

Type Plate Dispenser
Style Open Frame
Installation Type Floor Model (Mobile)
Material Stainless Steel
Compartments 4
Max. Dish Diameter 10 1/8 Inches
Capacity Per Tube Up to 72 plates or 36 bowls
Caster Size 4 Inches
Shipping Width 31 Inches
Shipping Depth 31 Inches
Shipping Height 36 Inches
Shipping Weight 188 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

This Atlas Metal MOPD4-10-1/8 plate dispenser is designed for plates up to a maximum diameter of 10 1/8 inches.
Each of the four self-elevating dispensing tubes can hold up to 72 plates or 36 bowls, providing ample capacity.
No, the MOPD4-10-1/8 model is an unheated plate dispenser, ideal for ambient temperature plate storage and transport.
Yes, the spring mechanism is designed for field adjustment, allowing you to fine-tune it for different plate weights to maintain the desired dispensing height.
The dispenser comes standard with 4-inch heavy-duty swivel casters for easy mobility. Locking brakes are available as an optional accessory.
