American Range ARSTG-12 Gas Griddles
Description
American Range ARSTG-12 Thermostatic Countertop Gas Griddle – 12″
30,000 BTU | Stainless Steel | Made in USAPack big-league performance into the smallest footprint. The ARSTG-12 couples a massive 1″ thick polished steel plate with a precise modulating thermostat, delivering rock-solid temperature control from 250 °F to 500 °F. Ideal for cafés, concessions, food trucks and any cookline where every inch matters.
Key Features
- Space-saving 12″ width without sacrificing production capacity.
- 1″ thick, highly polished steel plate retains heat for consistent searing & fast recovery.
- 21″ deep cooking surface increases usable landing zone for tortillas, burgers, veggies & more.
- One U-shaped 30,000 BTU/hr aluminized steel burner ensures even edge-to-edge coverage.
- Modulating thermostat with standing pilot maintains set temps within tight margins.
- Stainless steel front, 3″ side splashes & 4″ rear splash contain mess and protect adjacent equipment.
- 3″ spatula-wide grease trough drains to a 4½-qt stainless steel grease pan for quick clean-up.
- 4″ chrome-plated adjustable legs provide a comfortable 11 5⁄8″ working height and easy leveling.
- ETL & ETL-Sanitation listed for use in the United States and Canada.
- Designed & built in the USA; backed by a two-year limited parts & labor warranty.
Specifications
| Model | ARSTG-12 |
|---|---|
| Gas Type | Natural Gas or Liquid Propane (specify when ordering) |
| Total BTU Input | 30,000 BTU/hr |
| Burners | (1) U-shaped aluminized steel burner |
| Thermostat Range | 250 °F – 500 °F |
| Griddle Plate | 1″ thick smooth polished steel, 12″ W × 21″ D |
| Overall Dimensions | 12″ W × 32 9⁄16″ D × 18 7⁄16″ H |
| Working Height | 11 5⁄8″ on 4″ adjustable legs |
| Grease Management | 3″ trough to 4½-qt removable stainless steel pan |
| Exterior Construction | Stainless steel front, sides & splash guards |
| Gas Connection | ¾″ rear gas inlet; regulator included (NG 4.0″ WC / LP 10.0″ WC) |
| Shipping Weight | ≈ 145 lb |
| Certifications | ETL (US & Canada) & ETL-Sanitation |
| Warranty | 2-year limited parts & labor |
This appliance is manufactured for commercial use only and is not intended for residential installation.
