American Range ARGB-48 Raised Griddle/Broiler – 48" Gas Countertop
80,000 BTU • 23 kW • Made in USAHandle your breakfast rush and dinner service with one space-saving workhorse. The American Range ARGB-48 combines a heavy-duty griddle and high-performance broiler in a compact countertop footprint, giving chefs the versatility to sear, sauté, toast, and finish orders all on a single piece of equipment.
Why You’ll Love It
- 48" wide, 3/4" thick polished steel griddle plate for superb heat retention & fast recovery.
- (4) 20,000 BTU stainless burners—one every 12"—with manual, individual controls.
- Integrated raised broiler with pull-out rack for finishing steaks, melts & more.
- 3" wide front grease trough plus removable broiler grease tray for easy clean-up.
- All-stainless front & side panels withstand the rigors of busy kitchens and wipe clean in seconds.
- 4" adjustable legs let you level the unit on any countertop.
- ETL Sanitation & cETLus listed for safety and sanitation compliance.
- Backed by American Range’s limited parts-and-labor warranty.
Technical Specifications
| Model | ARGB-48 Raised Griddle/Broiler |
|---|---|
| Cooking Surface | 48" W x 24" D (1219 mm x 610 mm) |
| Griddle Plate | Polished steel, 3/4" (19 mm) thick |
| Total Input | 80,000 BTU/hr (23.0 kW) |
| Burners | 4 × 20,000 BTU tubular burners |
| Controls | Manual valves with individual pilots |
| Exterior Construction | Stainless steel front, sides & splash |
| Overall Dimensions | 48" W × 30" D × 16" H (plus 4" adjustable legs) |
| Gas Connection | 3/4" NPT rear manifold |
| Shipping Weight | ≈ 550 lb (249 kg) |
| Certifications | ETL Sanitation, cETLus |
Specify natural or LP gas at time of order. For altitudes above 2,000 ft (610 m), please advise factory. Minimum clearances to combustible construction: 12" sides, 4" rear. Install under adequate ventilation per NFPA 96.
Warranty & Support
- Two-year limited warranty on parts & labor
- 90-day warranty on broiler burners, grates & radiants
- Lifetime technical support from American Range’s U.S. service network
Gas equipment notice: Installation must be performed by a qualified technician in accordance with all local codes and the manufacturer’s instructions.
$5,409.32
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
American Range ARGB-48 gas griddle: 48" commercial countertop griddle, 3/4" steel plate, 4 burners, broiler rack, stainless, 80,000 BTU, ETL certified.
Manufacturer
American Range
Certifications
cETLus, ETL-Sanitation, Made in USA
Height
16.0in
Width
48.0in
Depth
32.0in
Shipping Weight
550.0lbs
Broiler Rack
2 position pull out broiler rack
Plate Thickness
3/4"
Construction
stainless steel
Specifications
Raised Griddle/Broiler, gas, 48" wide cooking surface, countertop, 3/4" thick polished griddle plate, (4) burners, manual controls, pull out broiler rack, removable broiler grease tray, 4" legs, 3" wide grease trough with grease tray, stainless steel front and sides, 23.0kW, 80,000 BTU, ETL-Sanitation, cETLus, Made in USA
