Wells VCS2000 Ventless Griddle Station

Bring full-size griddle production to spaces where traditional hoods, roof penetrations and ductwork are impossible. The Wells VCS2000 combines a powerful 22" × 18" thermostatic griddle, a fully self-contained 4-stage filtration hood and an ANSUL® R-102 fire-suppression system—everything you need to cook safely, legally and profitably almost anywhere.

True Ventless Technology

• Certified Type-1 recirculating hood (UL710B) – no ties to building ductwork.
• 4-stage filtration: stainless baffle, fire-rated fiberglass pre-filter, HEPA + carbon charcoal pack, final exhaust.
• 800 CFM vertical discharge keeps kitchens comfortable while operating at a quiet 68 dBA.
• Air-flow sensors & illuminated filter-life indicator maintain peak performance and grease removal.
• Interlock automatically disables griddle if filters are removed, clogged or a fire is detected.

Heavy-Duty Electric Griddle

• 22" × 18" (559 × 457 mm) cooking surface for breakfast plates, burgers, vegetables and more.
• Two independent thermostatic zones deliver precise 200 – 450 °F control.
• Removable stainless splash guard and front grease drawer speed up end-of-shift cleanup.
• Optional chrome-plated or grooved surfaces available (grooved not available with chrome).

Self-Contained Fire Protection

• Factory-installed ANSUL® R-102 wet-chemical system with fusible links & front-mounted manual pull.
• Complies with NFPA 96 Chap 13 – only on-site charge & tag by licensed ANSUL agent required.

Operator-Friendly Design

• Stainless cabinet base with dual-hinged storage doors keeps utensils and supplies close at hand.
• Two adjustable 6"–8" front legs & two 6" rear casters provide both mobility and stability.
• Fits through a standard 36" doorway—perfect for leased or historic spaces.
• Protected incandescent work light improves visibility on the cook surface.

Ideal Applications

• Food courts, cafés & kiosks
• Convenience stores & grocery delis
• Stadium suites & entertainment venues
• Ghost kitchens and pop-ups needing fast deployment

Filters & Accessories

• Required replacement filters (sold separately):
  • Pre-filter #22618 (one per unit)
  • HEPA/Charcoal filter pack #22619 (one per unit)
• Optional rear leg kit #22649 or caster kit #22650
• Chrome-plated or grooved griddle plate upgrades

Technical Specifications

Important Notes

• A minimum of 400 CFM make-up air is recommended in the installation area.
• ANSUL system must be charged & tagged on site prior to first use (operator responsibility).
• Ventless equipment is made-to-order and not eligible for return.

Ask about Middleby equipment financing to turn this ventless solution into manageable monthly payments.
