Wells (Middleby)  |  SKU: WG-3048-NAT

Wells (Middleby) WG-3048-NAT Gas Griddles

$10,330.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Owner's manual Warranty sheet
Related Searches
Gas Griddles Griddles & Flat Tops

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Wells WG-3048G 48" Gas Countertop Griddle

100,000 BTU | Natural Gas | Smooth ¾" Steel Plate

Turn out mountains of pancakes, burgers or steaks with the Wells WG-3048G. Four independent 25,000 BTU U-shaped burners heat a massive 47 ¾" × 24" cooking surface, while snap-action thermostats give you precise, zone-by-zone temperature control. Built entirely of stainless steel with an integrated splashguard and oversized grease drawer, this heavy-duty griddle is engineered for high-volume kitchens that can’t slow down.

Key Features

  • Powerful 100,000 BTU output from four U-shaped burners for even edge-to-edge heat.
  • Snap-action thermostats—one every 12"—deliver quick recovery and accurate temperature control.
  • Heavy ¾" polished steel plate resists warping and provides outstanding heat retention.
  • Stainless steel front, sides, and splashguard for durability and easy wipe-down cleaning.
  • Hinged front panel protects controls yet flips down for fast service access.
  • Full-width 4-quart grease drawer and 3⅞" front trough simplify cleanup.
  • Adjustable air shutters on each burner maximize combustion efficiency.
  • Factory-configured for natural gas; LP conversion kit available.
  • CSA-gas & NSF 4 certified for compliance with today’s health and safety codes.
  • Backed by a 1-year parts & labor warranty from Wells Manufacturing.

Applications

  • Breakfast service—pancakes, eggs, bacon and hash browns
  • Lunch rush—high-volume burgers, patty melts & quesadillas
  • Steak, chicken, seafood or veggies for dinner menus
  • Batch-cooking proteins for catering & commissary kitchens

Specifications

Model WG-3048G
Cooking Surface (W × D) 47 ¾" × 24" (1213 mm × 610 mm)
Plate Thickness ¾" (19 mm) polished steel
Number of Burners / BTU per Burner 4 × 25,000 BTU U-shaped
Total Input 100,000 BTU/hr
Controls 4 snap-action thermostats (one per 12" zone)
Gas Connection ¾" NPT (rear), 5.0" W.C. Natural Gas
LP kit: 10.0" W.C. Propane
Overall Dimensions (W × D) 47 13/16" × 30" (1214 mm × 762 mm)
Ship Weight ≈ 359 lb (163 kg)
Certifications CSA (ANSI Z83), NSF 4
Warranty 1-year parts & labor

Options & Accessories

  • Grooved ¾" steel plate for attractive char lines (special order).
  • Mirror-smooth chrome plate for faster heat transfer & easier cleanup (special order).
  • LP gas conversion kit.
  • Gas quick-disconnect hose & restraining device.
  • Equipment stand with undershelf.

Minimum clearances to combustible surfaces: 3" back & sides, 4" bottom. Specifications are subject to change without notice.

Need Financing?

Spread the cost with affordable, fixed monthly payments through Middleby Equipment Financing and keep your existing credit lines free. Apply in minutes ›

Features & Specs

Manufacturer

Wells (Middleby)

Certifications

NSF, CSA

Height

12.38in

Width

47.81in

Depth

30.0in

Shipping Weight

423.0lbs

Cooking Surface Width (side - side)

43" - 48"

Griddle Plate Finish

smooth steel

Cooking Surface Depth (front - back)

24" - 29"

Controls

thermostat / solid state controls

Exterior Finish

all stainless steel exterior

Plate Thickness

3/4"

Specifications

Griddle, countertop, natural gas, 47-3/4" W x 24" D cooking surface, smooth polished steel griddle plate, zoned thermostatic heat control, stainless steel construction, with splashguard, 100,000 BTU/HR, CSA, NSF 4
