Wells (Middleby)  |  SKU: RWN-3

Wells (Middleby) RWN-3 Drawer Warmers

$7,187.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Owner's manual Middleby financial flyer Warranty sheet
Related Searches
Countertop Food Warming Drawer Warmers

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Wells RWN-3 Narrow 3-Drawer Warming Unit

Freestanding, space-saving hot holding with individual temperature & humidity control

Keep three different menu items at their ideal serving condition without giving up precious counter space. The Wells RWN-3 combines a compact 20¼-inch footprint with full-size pan capacity in every drawer—perfect for rolls, proteins, sides and more.

Key Features

  • Three independently controlled drawers—serve hot & crispy in one, warm & moist in another.
  • Narrow 20¼" width accommodates standard 12" × 20" pans (up to 6" deep).
  • Exclusive self-latching mechanism provides smooth, one-touch closure.
  • Durable stainless steel cabinet, tracks and bearings for long-term reliability.
  • Adjustable front vents for precise humidity control.
  • Wide temperature range 90 °F – 210 °F (32 °C – 99 °C).
  • Fully insulated body boosts efficiency and keeps exterior cool.
  • cULus Listed & NSF certified for commercial kitchens.

At-a-Glance Capacity

  • Approx. 8 dozen dinner rolls per drawer (≈ 24 dozen total)
  • OR three full-size pans of vegetables, proteins, tortillas, pastries and more

Specifications

Model RWN-3
Drawers 3, self-latching
Temperature Range 90 °F – 210 °F (32 °C – 99 °C)
Pre-heat to 175 °F 15 min (120/240 V)  |  22 min (208 V)
Pan Capacity (3) 12" × 20" pans, up to 6" deep
Width 20 ¼" / 514 mm
Depth 26 5⁄16" / 668 mm
Height 31 ⅛" / 791 mm (with 4" legs)
Installed Weight 147 lb / 67 kg
Electrical 120 V 1 ph, 1,350 W, 11.3 A, NEMA 5-15P
Electrical 208 V 1 ph, 1,014 W, 4.9 A, NEMA 6-15P
Electrical 240 V 1 ph, 1,350 W, 5.6 A, NEMA 6-15P
Certifications cULus, NSF Std 4
Warranty 1-year parts & labor
Important: Unit must be connected to a dedicated circuit by a qualified professional. Always verify local electrical codes before installation.

What’s Included

  • (3) Stainless steel 12" × 20" pans
  • Factory-installed 4" adjustable legs
  • User & service manuals

Popular Accessories (sold separately)

  • Stainless steel replacement pan — part #22228
  • 10" caster kit, set of 4 (two locking) — part #21034
  • 3½" low-profile caster kit, set of 4 (all locking) — part #22201
  • 6" leg kit, set of 4 — part #20576

Need help selecting voltage, accessories or ship-dates? Our equipment specialists are ready to assist you.

Features & Specs

Manufacturer

Wells (Middleby)

Certifications

NSF, cULus

Height

31.13in

Width

20.25in

Depth

26.31in

Shipping Weight

165.0lbs

Controls

thermostatic controls

Style

narrow drawer

Drawers

3 drawers

Specifications

Warming Drawer Unit, freestanding, narrow, three drawers, capacity approximately 8 dozen rolls/drawer, humidity and thermostat controls, stainless steel construction, cULus, NSF
