Wells RCP-600 6-Pan Drop-In Refrigerated Cold Food Well

Self-Contained, 115V, 1/2 HP, Six 12" x 20" Pans

Keep pre-chilled ingredients organized and ready to serve with a self-contained drop-in cold well built for six full-size pans.

  • Holds six 12" x 20" food pans to keep cold ingredients organized and accessible.
  • Self-contained refrigeration simplifies installation in a counter or serving line.
  • Individual thermostatic controls and an on/off switch help maintain consistent holding temperatures.
  • Stainless steel inner liner, top, and flange add durability and simplify cleaning.
  • Insulated pan construction helps maintain cold temperatures and improve efficiency.
  • 115V, 60 Hz, 1-phase operation with 6.4 amps and a NEMA 5-15P plug.

Overall Dimensions:

86.0"W x 25.38"D x 24.5"H

Product Weight:

290.0 lb

Self-Contained Drop-In Design

Built-in refrigeration allows the unit to be installed directly into a counter or buffet line.

Six Full-Size Pan Capacity

Accommodates six 12" x 20" food pans for cold holding and service.

Individual Thermostatic Controls

Helps maintain consistent temperatures for stored ingredients.

On/Off Switch

Provides simple day-to-day operation and control.

Stainless Steel Food Zone Surfaces

Stainless steel inner liner, top, and flange support durability and easier cleanup.

Insulated Pan Construction

Insulation helps keep food cold while reducing energy loss.

1-Inch Drain

Makes draining and cleaning the unit easier.

Commercial Electrical Package

Operates on 115V, 60 Hz, 1-phase power with 6.4 amps and a NEMA 5-15P plug.

R-404A Refrigeration System

Uses R-404A refrigerant and 1/2 HP refrigeration for cold holding performance.

Steel Exterior Body

Durable steel body is suited for commercial foodservice use.

Type Cold Well
Style Self-Contained Refrigeration
Installation Type Drop-In
Pan Capacity 6 Full-Size Pans
Pan Size 12 Inches x 20 Inches
Controls Individual Thermostatic
Material Steel
Interior Finish Stainless Steel
Finish Galvanized Steel
Drain Connection Size 1 Inch
Refrigerant Type R-404A
Horsepower 1/2 HP
Voltage 115 Volts
Amps 6.4 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Shipping Width 86 Inches
Shipping Depth 26 Inches
Shipping Height 25 Inches
Shipping Weight 290 Pounds
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download PDF Install sheet PDF Download PDF Owner's manual PDF Download PDF Middleby financial flyer PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It holds six 12" x 20" food pans.
Yes. It is a self-contained, drop-in refrigerated cold well.
It operates on 115V, 60 Hz, 1-phase power and uses a NEMA 5-15P plug.
Yes. The unit includes a 1-inch drain for easier cleaning and drainage.
It uses R-404A refrigerant.
The unit has a stainless steel inner liner, top, and flange, with a steel exterior body.
