Wells (Middleby)  |  SKU: RCP-200

Wells (Middleby) RCP-200 Steam Tables & Food Wells

$8,550.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Owner's manual Install sheet Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Wells RCP-7200 Refrigerated Drop-In Cold Food Well – 2 Pan

Self-contained, NSF-7 certified cold holding in a compact drop-in platform

Keep salads, toppings, desserts and grab-n-go meals safely chilled and perfectly presented with the Wells RCP-7200. This two-pan, self-contained cold well drops seamlessly into your countertop and delivers precise temperature control without the cost and complexity of a remote system.

Why You’ll Love It

  • Holds two full-size 12" × 20" hotel pans (or fractional pans with optional adapter bars)
  • 3" recessed top edge meets NSF-7 cold-holding requirements and keeps product fresher, longer
  • Individual thermostatic controls for each pan slot – dial in temperatures for mixed menus
  • 18-gauge stainless steel top, flange & liner for maximum durability and easy sanitation
  • Fully foamed-in-place insulation minimizes energy use and condensation
  • Easy-access on/off switch with 8 ft. cord and NEMA 5-15P simplifies installation – just drop in & plug in
  • 1" NPT center drain speeds cleaning and helps prevent standing water
  • Eco-friendly R-513A refrigerant, 1/4 HP compressor and air-cooled condenser
  • Made in the USA and backed by a 1-year parts & labor warranty (optional 5-year compressor coverage)

At-a-Glance Specifications

Model RCP-7200 (2-pan)
Pan Capacity (2) full-size 12" × 20" pans, 6" deep max
Exterior Dimensions 32 ³⁄₄" W × 27 ¹⁄₈" D × 26 ¹⁄₈" H
Counter Cut-out 31 ¹⁄₂" W × 25 ⁷⁄₈" D
Refrigerant / Charge R-513A / 10 oz
Compressor 1/4 HP, air-cooled, self-contained
Electrical 115 V / 60 Hz / 1-φ, 5 A, cord & plug (NEMA 5-15P)
Drain 1" NPT (center pan)
Construction 18-ga stainless steel top, flange & liner; corrosion-resistant steel exterior body
Certifications NSF-7, cULus
Warranty 1-yr parts & labor • Optional 5-yr compressor

Popular Accessories (Sold Separately)

  • Perforated bottom strainer plate – keeps ice above the drain to prevent clogging
  • Adapter bars – arrange fractional pans for ultimate menu flexibility
  • Pan rails – add a finished look and secure pans in high-volume environments

Need a different size? Wells offers the RCP series in 1–6 pan configurations. Contact us for help selecting the perfect fit for your line-up.

Features & Specs

Manufacturer

Wells (Middleby)

Certifications

NSF, cULus

Height

24.5in

Width

31.0in

Depth

25.38in

Shipping Weight

182.0lbs

Width (side - side)

31 - 36 inches

Style

self-contained refrigeration

Pan Qty

2-pan

Insulation

insulated

Layout

straight

Pan Size

full-size (12" x 20")

Finish

galvanized steel outer liner

Specifications

Cold Food Well Unit, drop-in, self-contained refrigeration, (2) 12" x 20" pan capacity, on/off switch with individual thermostatic controls, insulated pan, 1" drain, stainless steel inner liner, top & flange, steel exterior body, R-513A refrigerant, 1/4 HP, 115v/60/1-ph, 5.5 amps, NEMA 5-15P, NSF, cULus
