Wells (Middleby)

Wells Drop-In Self-Contained Refrigerated Cold Food Well, 1 Full-Size Pan, 115V

SKU: RCP-100
$8,021.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Cold Well Food Bars & Buffets Food Holding & Warming Equipment Food Wells & Serving Lines New Arrivals Restaurant Equipment Steam Tables & Food Wells Wells (Middleby)

Wells Drop-In Self-Contained Refrigerated Cold Food Well, 1 Full-Size Pan, 115V

Standard 12" x 20" pan capacity with thermostatic controls

Keep pre-chilled foods cold, fresh, and ready to serve with a compact drop-in cold well that uses self-contained refrigeration and simple thermostatic control.

  • Drop-in refrigerated cold well for food bars, buffets, and serving lines.
  • Holds one standard 12" x 20" food pan; fractional-pan accessories are available.
  • Self-contained refrigeration with thermostatic control and on/off switch.
  • Insulated stainless steel food zone with 1" drain for easier cleaning.
  • 115V cord-and-plug operation with NEMA 5-15P connection.
  • NSF and cULus listed for commercial foodservice use.

Overall Dimensions:

17.38"W x 25.38"D x 24.5"H

Product Weight:

89.0 lb

Drop-In Self-Contained Design

Installs into a countertop or table cutout and does not require remote refrigeration lines.

One Full-Size Pan Capacity

Designed to hold one standard 12" x 20" food pan for refrigerated holding.

Thermostatic On/Off Controls

Simple thermostatic controls help maintain consistent cold holding temperatures.

Fully Insulated Construction

Foamed-in-place insulation helps keep food cold while reducing energy use.

Stainless Steel Food Zone

Stainless steel top and liner provide durability and a cleanable food-contact surface.

1-Inch Drain

Built-in drain supports straightforward drainage and cleaning.

NSF-7 Recessed Top Edge

A recessed top edge helps the unit meet NSF-7 performance requirements.

R-513A Refrigeration System

Uses CFC-free R-513A refrigerant for cold holding performance.

Type Cold Food Well
Style Self-Contained Refrigeration
Installation Type Drop-In
Pan Capacity 1 Full-Size Pan
Pan Size Full-Size (12" x 20")
Controls Thermostatic
Voltage 115 Volts
Amps 5.5 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Cord Length 8 Feet
Horsepower 1/4 HP
Refrigerant Type R-513A
Drain Connection Size 1 Inch
Drain Connection Required
Material Steel
Interior Finish Stainless Steel
Finish Galvanized Steel
Country of Origin USA
Selling Unit Each
Units Per Case 1
Shipping Width 18 Inches
Shipping Depth 26 Inches
Shipping Height 25 Inches
Shipping Weight 89 lb.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Warranty & Protection

Limited 1-year parts and labor warranty.

Documents

PDF Cutsheet PDF Download PDF Middleby financial flyer PDF Download PDF Owner's manual PDF Download PDF Install sheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It is designed for one standard 12" x 20" food pan.
Yes. The unit uses self-contained refrigeration, so it does not require remote refrigeration lines.
The unit operates on 115V, 60 Hz, single-phase power and uses a NEMA 5-15P plug.
Yes. It requires a 1-inch drain connection for installation and cleaning.
The top and liner are stainless steel, with a steel exterior body.
