Wells (Middleby) MOD-300TD Steam Tables & Food Wells
Description
Wells MOD300TD Drop-In Three-Well Food Warmer
Top-mount • Thermostatic controls • Wet or dry operation • Integrated drainsDeliver every dish at the ideal serving temperature while keeping your counter line looking seamless. The Wells MOD300TD is a heavy-duty, built-in warmer that holds three full-size (12" × 20") steam-table pans— or the fractional pans you already own—with the flexibility of wet or dry operation and individual, recessed thermostatic controls.
Why You’ll Love It
- Three deep-drawn stainless steel wells accept standard 12" × 20" pans or fractional equivalents.
- Wet or dry holding—water bath recommended for maximum food quality.
- Independent thermostatic controls and temperature-ready indicator lights for each well.
- 1⁄2" NPT drains on every well speed change-outs and end-of-day cleanup.
- Fully insulated aluminized-steel housing conserves energy and stays cool to the touch—ideal for non-metal counters.
- One-piece stainless steel top flange with WellsLok™ mounting clamps for fast, tool-free drop-in installation.
- High-limit safety shuts elements off to prevent overheating.
- Powerful tubular heating elements deliver fast pre-heat and even temperature distribution.
- UL & NSF listed; backed by a 1-year parts & labor warranty.
At-a-Glance Specs
| Model | MOD300TD |
|---|---|
| Capacity | (3) full-size 12" × 20" pans or fractional equivalents |
| Operation | Wet or Dry (wet recommended) |
| Control Type | Individual thermostatic knobs with status lights (front recessed panel) |
| Drain | (3) ½" NPT drains—one for each well |
| Heating Elements | Tubular, beneath each well |
| Voltage / Phase | 208 V or 240 V, ships 3-phase – field-convertible to 1-phase |
| Wattage | 3,720 W @208 V | 4,950 W @240 V (≈1,240–1,650 W per well) |
| Overall Dimensions | 43 ½" W × 23 ⅝" D × 9 ¾" H |
| Control Panel | 18" W × 6 ¼" H |
| Construction | Stainless steel wells & flange; insulated aluminized-steel housing |
| Certifications | UL, cUL, NSF |
| Warranty | 1-Year Limited Parts & Labor |
Optional Accessories
- Adaptor tops for round insets
- Inset pans with lids & 8 oz soup ladles
- Drain screens or drain-manifold kits
- Auto-fill water system (factory option)
- 72" wiring harness or WellsLok™ extension kits for thick wood counters
