Wells HDTG4830G 48" Heavy-Duty Thermostatic Gas Griddle
Middleby Essentials in-stock item – fast, reliable shippingBuilt for the busiest kitchens, the Wells HDTG4830G delivers the power, precision, and durability you need in a compact countertop footprint. Four independent thermostats drive a total of 120,000 BTU beneath a 3/4" thick steel plate, giving you lightning-fast recovery and edge-to-edge even heat for breakfast, lunch, and dinner rushes.
Key advantages
- 3/4" polished steel griddle plate for rapid pre-heat & quick recovery
- Four 30,000 BTU U-shaped burners (total 120,000 BTU) with individual thermostat controls (200 – 450 °F)
- Stainless steel front, sides, and 4-sided splashguard stand up to daily abuse
- Full-width front grease trough & large removable drip pan for fast clean-up
- Field convertible from natural gas to LP – conversion kit included
- Removable stainless front panel provides tool-free service access
- 4" adjustable heavy-duty steel legs for level installation
- NSF & cCSAus certified for commercial use
- 1-year parts & labor warranty backed by Wells’ nationwide service network
At-a-glance specs
| Model | HDTG4830G (Thermostatic) |
|---|---|
| Cooking surface (W × D) | 47 3/4" × 23 3/4" (1213 × 603 mm) |
| Overall dimensions (W × D × H) | 48 1/8" × 31 11/16" × 17" (1222 × 804 × 433 mm) incl. 4" legs |
| Total BTU | 120,000 BTU (Natural Gas) / 120,000 BTU (LP) |
| Gas connection | 3/4" NPT (left rear) |
| Thermostat range | 200 °F – 450 °F (93 – 232 °C) |
| Clearances (non-combustible) |
Back 0" | Sides 0" | Bottom 4" |
| Shipping / Installed weight | 507 lb / 393 lb (230 kg / 178 kg) |
| Certifications | NSF, cCSAus |
| Warranty | 1 year parts & labor |
Installation requirement: This appliance must be installed, adjusted, and serviced by qualified personnel in accordance with local codes and the manufacturer’s instructions. Proper ventilation and clearance are essential for safe operation.
Need financing? Middleby Equipment Financing can turn this purchase into affordable fixed monthly payments.
$3,320.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Wells (Middleby) 47.75" countertop gas griddle, 120,000 BTU, 3/4" plate, 4 thermostats, stainless steel, NSF certified.
Manufacturer
Wells (Middleby)
Certifications
NSF, cCSAus
Height
17.0in
Width
48.13in
Depth
33.25in
Shipping Weight
507.0lbs
Cooking Surface Width (side - side)
43" - 48"
Griddle Plate Finish
smooth steel
Exterior Finish
all stainless steel exterior
Controls
thermostat / solid state controls
Cooking Surface Depth (front - back)
24" - 29"
Plate Thickness
3/4"
Specifications
(MIDDLEBY ESSENTIALS ITEM) Griddle, countertop, natural gas, 47-3/4" W x 23-3/4" cooking surface, 3/4" griddle plate, (4) thermostat controls, splashguard, stainless steel construction, 4" steel legs, 120,000 BTU, NSF, cCSAus
