Vulcan IRX Technology VTEC25 Countertop Gas Infrared Charbroiler, 25-1/2 Inch, 2 Burners

SKU: VTEC25
$7,023.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Charbroilers Charbroilers & Grills Commercial Grills Gas Charbroilers New Arrivals Restaurant Equipment Vulcan

Vulcan IRX Technology VTEC25 Countertop Gas Infrared Charbroiler, 25-1/2 Inch, 2 Burners

Manual Controls, Piezo Ignition, Stainless Steel Grids

This compact infrared charbroiler delivers fast, even heat and juicy results with 2 high-output burners and easy-clean stainless steel construction.

  • 100% IRX infrared cooking platform promotes even heat and efficient performance.
  • Two 22,000 BTU burners provide 44,000 BTU total output for demanding service.
  • Manual heat controls and piezo spark ignition make operation straightforward.
  • Stainless steel cooking grids, sides, control panel, top trim, and backsplash add durability.
  • Full-width crumb tray plus removable heat shield and splash guard help speed cleanup.
  • 4-inch adjustable legs and a rear NPT gas connection support countertop installation.

Overall Dimensions:

25.38"W x 35.13"D x 16.38"H

Product Weight:

151.0 lb

IRX Infrared Cooking Platform

Uses an atmospheric burner, emitter panel, and stainless steel cooking grid to deliver infrared heat with consistent results.

Two High-Output Burners

Each burner is rated at 22,000 BTU/hr for a total of 44,000 BTU/hr.

Manual Heat Control

Features one high-range heat control valve per burner with chrome burner control knobs.

Piezo Spark Ignition

Direct ignition piezo spark igniters help provide quick and reliable startup.

Stainless Steel Construction

Includes stainless steel sides, control panel, top trim, backsplash, and cooking grids for durability.

Easy-Clean Components

Full-width stainless steel crumb tray and removable stainless steel heat shield/splash guard simplify cleanup.

Adjustable Legs And Rear Gas Connection

4-inch adjustable legs and a 3/4-inch NPT rear gas connection are provided; a gas pressure regulator is supplied.

Type Infrared Charbroiler
Style Countertop
Installation Type Countertop
Controls Manual
Material Stainless Steel
BTU 44,000 BTU/hr
Cooking Surface Width 22 Inches
Cooking Surface Depth 25.25 Inches
Gas Connection Size 3/4 Inch NPT Rear
Shipping Width 26 Inches
Shipping Depth 36 Inches
Shipping Height 17 Inches
Shipping Weight 151 Pounds
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1-year limited parts and labor

Documents

PDF Cutsheet PDF Download PDF Sell sheet PDF Download PDF California rebate PDF Download PDF Parts list PDF Download PDF Vtec smart chain PDF Download PDF Owner's manual PDF Download PDF Video PDF Download PDF Vtec nicor energy PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The VTEC25 has 2 burners, each rated at 22,000 BTU/hr for 44,000 BTU/hr total.
It uses direct ignition piezo spark igniters and manual heat controls with one heat control valve per burner.
The documents say to specify the type of gas when ordering; installation requirements list both natural gas and propane settings.
Natural gas requires 4.0 inches W.C., and propane gas requires 10.0 inches W.C. A gas pressure regulator is supplied with the unit.
The VTEC25 has a 22-inch by 25.25-inch broiling area.
Optional accessories include stainless steel fish grates with 1/4-inch rib spacing and a stainless steel stand with undershelf and casters.
