Vulcan VTC24B Heavy Duty 24-Inch Infrared Gas Charbroiler with Cabinet Base

Manual Controls, Stainless Steel Construction, 44,000 BTU

A rugged 24-inch infrared charbroiler with a cabinet base, delivering 44,000 BTU/hr and durable stainless steel construction for high-volume kitchens.

  • 24-inch infrared charbroiler delivers 44,000 BTU/hr total input for high-heat commercial cooking.
  • Cabinet base version adds enclosed under-unit storage with a stainless steel door and removable shelf.
  • Stainless steel front, front top ledge, sides, base, and stub back are built for demanding kitchen use.
  • Individual high-range heat control valves and direct piezo ignition support responsive operation.
  • Heavy-duty steel infrared emitter panels and stainless steel cooking grids help deliver consistent charbroiling performance.

Overall Dimensions:

24.0"W x 36.75"D x 36.0"H

Product Weight:

405.0 lb

Infrared Burner System

One 22,000 BTU/hr patented infrared burner system per cooking grid provides efficient, high-heat output.

Stainless Steel Construction

Stainless steel front, front top ledge, sides, base, and stub back improve durability and simplify cleaning.

Cabinet Base Storage

Enclosed cabinet base includes a stainless steel door, universal rack guides, and one removable shelf.

Manual Heat Controls

One high-range heat control valve per burner lets operators adjust heat zone by zone.

Piezo Spark Ignition

Direct ignition piezo spark igniters provide quick start-up without a standing pilot.

Stainless Steel Cooking Grids

11 inch by 25 inch stainless steel cooking grids are designed for dependable charbroiling performance.

Full-Width Crumb Tray

A full-width stainless steel crumb tray helps catch drippings and supports easier cleanup.

Adjustable Legs

6-inch adjustable stainless steel legs help level the unit during floor installation.

Type Infrared Charbroiler
Style Cabinet Base
Installation Type Floor Model
Controls Manual
BTU 44,000 BTU/hr
Gas Inlet Pressure 6.0 Inches W.C. Natural Gas / 10.0 Inches W.C. Propane
Gas Connection Size 1 1/4 Inch NPT
Material Stainless Steel
Finish Stainless Steel
Selling Unit Each
Units Per Case 1
Shipping Width 24 Inches
Shipping Depth 37 Inches
Shipping Height 36 Inches
Shipping Weight 405 Pounds

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1-year limited parts and labor

Documents

PDF Cutsheet PDF Download PDF Sell sheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The VTC24B is the cabinet base version, while the VTC24 is the modular version.
Natural gas requires 6.0 inches W.C., and propane requires 10.0 inches W.C. A properly sized gas pressure regulator must be furnished and installed.
The unit requires 10 inches of clearance at the rear and sides for combustible construction, and 0 inches for non-combustible construction.
Yes. It includes a one-year limited parts and labor warranty.
