Key specifications

BTU
4,090 BTU
Amps
12 Amps
Phase
1-Phase
Dimensions
96.0"W × 34.13"D × 26.0"H
Type
Refrigerated Base
Style
Flat Top
Spec sheet
Vulcan SKU: VSC96

Vulcan VSC96 96-Inch 6-Drawer Refrigerated Chef Base

$26,882.00
/each
Estimated to ship in 8–11 business days Free Shipping
Edge Style
Width
Refrigeration application
Refrigeration system location
Cabinet length
Mobility
Exterior back

Need something else? Contact us.

Included: Vulcan warranty One-year parts and labor warranty with a five-year refrigeration compressor parts warranty

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $2,487/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Specifications

Type Refrigerated Base
Style Flat Top
Installation Type Floor Model
Material Stainless Steel
Finish Galvanized and Stainless Steel
Top Material Stainless Steel
Drawer Material 430 Stainless Steel
Width 96 in
Drawer Count 6 Drawers
Pan Size 12 x 20 x 6 in
Pan Capacity 12 Pans
Pan Orientation Front to Back
Refrigeration Type Self-Contained
Refrigeration Location Side Mounted
Refrigerant Type R-404A
Temperature Range 34 to 38°F
Compressor Horsepower 1/2 HP
BTU 4,090 BTU
Voltage 115 Volts
Amps 12 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Cord Length 9 ft
Controls Microprocessor
Condensate Evaporator Automatic
Caster Size 3 in

Description

The Vulcan VSC96 is a 96-inch self-contained refrigerated drawer base with a flat stainless steel top and six drawers.

Its side-mounted refrigeration system uses R-404A refrigerant and has a standard operating temperature of 34 to 38°F. The drawers accommodate 12 x 20 x 6 in pans, with a listed total pan capacity of 12.

  • Stainless steel front and sides with galvanized steel exterior back and bottom
  • Microprocessor control system and automatic condensate evaporator
  • Front-breathing design for zero-clearance installation
  • Three-inch casters on an adjustable channel moving system

Overall Dimensions:

96.0"W x 34.13"D x 26.0"H

Product Weight:

525.0 lb

Self-Contained Refrigeration

The side-mounted, balanced refrigeration system uses R-404A refrigerant and has a standard operating temperature of 34 to 38°F.

Six Refrigerated Drawers

The six drawers accommodate 12 x 20 x 6 in pans; dimensional data lists a total pan capacity of 12 pans with front-to-back orientation.

Flat Stainless Steel Top

The unit has a flat stainless steel top.

Stainless Steel Construction

The front and sides are stainless steel, while the exterior back and bottom are galvanized steel.

Microprocessor Controls

The water-resistant microprocessor control system includes a 3-digit LED display and Fahrenheit or Celsius temperature display capability.

Drawer Operation

Drawers include self-closing and stay-open features, full-length handles with gasket guards, and magnetic snap-in gaskets.

Caster System

Three-inch casters are mounted on an adjustable channel moving system.

Front-Breathing Design

The front-breathing design is specified for zero-clearance installation.

Frequently Asked Questions

The VSC96 has six refrigerated drawers.
The cutsheet specifies 12 x 20 x 6 in pans and lists a total pan capacity of 12 pans.
The standard operating temperature is 34 to 38°F.
It uses 115 Volts, 12 Amps, 60 Hz, and 1-Phase electrical service with a NEMA 5-15P plug and a 9-ft cord.
Yes. The refrigeration system is self-contained and side mounted.
Yes. Three-inch casters on an adjustable channel moving system are included as standard.
The listed dimensions are 96 in wide, 34.13 in deep, and 26 in high.
