Key specifications

BTU
120,000 BTU
Amps
2 Amps
Phase
1-Phase
Dimensions
48.0"W × 33.1"D × 18.8"H
Type
Griddle
Style
Heavy Duty
Spec sheet
Vulcan SKU: VCCG48-AS

Vulcan VCCG48-AS 48-Inch Countertop Gas Griddle

$13,174.00
/each
Estimated to ship in 8–11 business days Free Shipping
Width
Feature
Gas type
Burner type
Griddle plate
Steel plate surface
Gas Connector

Need something else? Contact us.

Included: Vulcan warranty One-year limited parts and labor warranty

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $1,219/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Specifications

Type Griddle
Style Heavy Duty
Installation Type Countertop
Material Stainless Steel
Chassis Material Aluminized Steel
Plate Material Steel
Finish Smooth Steel
Cooking Surface Width 48 Inches
Cooking Surface Depth 24 Inches
Plate Thickness 1 Inch
Burner Count 4
Burner Type Atmospheric
BTU 120,000 BTU
Controls Solid State Thermostat
Temperature Range 200°F to 550°F
Drawer Count 1
Grease Drawer Capacity 6 Quarts
Voltage 120 Volts
Amps 2 Amps
Hertz 50/60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Cord Length 6 ft

Description

Vulcan VCCG48-AS is a heavy-duty countertop gas griddle with a 48-inch-wide by 24-inch-deep cooking surface and a 1-inch-thick smooth steel plate.

Four atmospheric burners provide 120,000 BTU and are independently controlled by solid-state thermostats for each 12-inch cooking zone. Electronic spark ignition with pilot protection supports operation, while the stainless steel front, sides, front top ledge, grease trough, rear splash, and tapered side splashes support commercial kitchen use.

  • One 6-quart stainless steel grease drawer
  • Four 4-inch adjustable legs
  • 120-volt electrical connection with NEMA 5-15P plug
  • CSA, ENERGY STAR, and NSF certifications

Overall Dimensions:

48.0"W x 33.1"D x 18.8"H

Product Weight:

575.0 lb

Cooking Surface

Provides a 48-inch-wide by 24-inch-deep cooking surface.

Steel Plate

Uses a 1-inch-thick smooth steel griddle plate.

Atmospheric Burners

Includes four atmospheric type U-shaped aluminized steel burners with 120,000 BTU total input.

Zone Control

Each 12-inch cooking zone is independently controlled by a solid-state thermostat.

Ignition and Protection

Electronic spark ignition includes pilot protection.

Grease Management

Includes one high-capacity 6-quart stainless steel grease drawer and a front grease trough.

Construction

Features a stainless steel front, sides, front top ledge, rear splash, and tapered side splashes.

Adjustable Legs

Includes 4-inch adjustable legs.

Frequently Asked Questions

The cooking surface is 48 inches wide by 24 inches deep.
The smooth steel plate is 1 inch thick.
It has four atmospheric burners rated at 120,000 BTU total.
Each 12-inch cooking zone is independently controlled by a solid-state thermostat.
Yes. It has electronic spark ignition with pilot protection.
The griddle uses 120 volts, 2 amps, 50/60 Hz, single-phase power with a NEMA 5-15P plug and a 6-foot cord.
It includes a one-year limited parts and labor warranty from the date of original installation for defects in material and workmanship.
