Vulcan

Vulcan V Series 36-Inch Heavy Duty Gas Range with 2 Open Burners and 18-Inch Manual Griddle, Cabinet Base

SKU: V2BG18B
$10,358.68
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Gas Ranges Commercial Ranges Gas Ranges New Arrivals Ranges Restaurant Equipment Vulcan

Vulcan V Series 36-Inch Heavy Duty Gas Range with 2 Open Burners and 18-Inch Manual Griddle, Cabinet Base

Stainless Steel, Floor Model, 100,000 BTU

A durable 36-inch heavy-duty gas range that combines two high-output open burners with an 18-inch manual griddle and a rugged cabinet base for versatile back-of-house cooking.

  • Combines two 35,000 BTU open burners with an 18-inch manual griddle in a compact 36-inch footprint.
  • Cabinet base design includes stainless steel doors, rack guides, and a removable shelf for added storage.
  • Heavy-duty stainless steel construction helps withstand demanding commercial kitchen use.
  • Individual pilots and controls for each burner support precise operation.
  • 6-inch adjustable stainless steel legs help with leveling during installation.
  • 100,000 BTU/hr total input delivers strong heat output for high-volume cooking.

Overall Dimensions:

36.0"W x 41.88"D x 40.5"H

Product Weight:

432.0 lb

High-Output Open Burners

Two 35,000 BTU/hr open top burners with lift-off heads for powerful cooking and easier cleaning.

18-Inch Manual Griddle

Includes a 3/4-inch ground steel griddle plate with a 30,000 BTU/hr griddle burner.

Cabinet Base Storage

Stainless steel cabinet base doors, universal rack guides, and one removable shelf provide convenient undercounter storage.

Stainless Steel Construction

Stainless steel front, front top ledge, burner box, sides, base, and stub back add durability and a clean appearance.

Independent Burner Controls

Individual pilots and controls for each burner help provide consistent operation and burner-by-burner control.

Gas Connection

Features a 1 1/4-inch front gas manifold and a capped 1 1/4-inch rear gas connection.

Adjustable Legs

6-inch adjustable stainless steel legs help level the range during installation.

Total Heat Input

100,000 BTU/hr total input for demanding commercial cooking applications.

Type Gas Range
Style Heavy Duty
Installation Type Floor Model
Material Stainless Steel
Controls Manual
BTU 100,000 BTU/hr.
Gas Connection Size 1 1/4 Inches
Shipping Width 36 Inches
Shipping Depth 42 Inches
Shipping Height 41 Inches
Shipping Weight 432 Pounds
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1-year limited parts and labor

Documents

PDF Cutsheet PDF Download PDF Service manual PDF Download PDF Installation & operation PDF Download PDF Sell sheet PDF Download PDF Video PDF Download PDF Parts manual PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

This model includes two open burners, an 18-inch manual griddle, and a cabinet base.
The total input is 100,000 BTU/hr.
Specify natural gas or propane when ordering. The installation instructions list 6.0 inches W.C. for natural gas and 10.0 inches W.C. for propane.
For combustible surfaces, the rear and sides require 10 inches. For non-combustible surfaces, the rear and sides require 0 inches.
Yes. The documentation states that an adequate ventilation system is required for commercial cooking equipment.
It comes with a one-year limited parts and labor warranty.
