Vulcan V Series 36-Inch Heavy Duty Gas Range with Radial Fin French Top and Standard Oven

Stainless Steel, 95,000 BTU, 6-Inch Adjustable Legs

Built for high-volume commercial kitchens, this 36-inch gas range pairs a polished French top with a standard oven and rugged stainless steel construction.

  • 36-inch heavy duty gas range with a radial fin French top and standard oven base
  • 95,000 BTU/hr total input for demanding commercial cooking
  • Stainless steel front, front top ledge, sides, base, burner box, and stub back
  • Standard oven includes one rack, porcelain cavity, and three rack positions
  • 6-inch adjustable stainless steel legs and 1 1/4-inch gas connection for installation
  • Commercial-use only design intended for restaurant and institutional kitchens

Overall Dimensions:

36.0"W x 36.75"D x 36.0"H

Product Weight:

685.0 lb

Radial Fin French Top

Polished cast iron French top provides flexible heat zones for pots and pans.

Standard Oven Base

Built-in standard oven includes a porcelain-lined cavity and one oven rack.

High-Output Burners

Three cast ring burners total 45,000 BTU/hr, complemented by a 50,000 BTU/hr oven burner for 95,000 BTU/hr total input.

Individual Burner Controls

Each top burner has its own pilot and control for precise heat management.

Stainless Steel Construction

Stainless steel front, front top ledge, sides, base, burner box, and stub back are built for heavy-duty service.

Adjustable Legs

6-inch adjustable stainless steel legs help level the unit during installation.

Heavy-Duty Oven Door

Counterweight door hinges and three rack positions improve access and cooking flexibility.

Gas Hookup

1 1/4-inch front manifold and capped rear gas connection simplify installation.

Type Heavy Duty Gas Range
Style Radial Fin French Top
Installation Type Floor Model
Capacity 1 Standard Oven
Material Stainless Steel
Interior Finish Porcelain
BTU 95,000 BTU/hr
Gas Connection Size 1 1/4 Inches
Shipping Width 36 Inches
Shipping Depth 37 Inches
Shipping Height 36 Inches
Shipping Weight 685 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1-year limited parts and labor

Documents

PDF Cutsheet PDF Download PDF Service manual PDF Download PDF Video PDF Download PDF Parts manual PDF Download PDF Installation & operation PDF Download PDF Sell sheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It includes one oven rack and a porcelain oven cavity.
The total input is 95,000 BTU/hr.
Natural gas requires 6.0 in. W.C., and propane requires 10.0 in. W.C. Specify gas type when ordering.
The unit measures 36 inches wide by 36.75 inches deep by 36 inches high on 6-inch adjustable legs.
No. It is manufactured for commercial installation only.
The standard oven allows three rack positions.
