Vulcan V Series 18-Inch Heavy Duty Full Hot Top Gas Range with Cabinet Base

30,000 BTU, Stainless Steel Exterior, 6-Inch Adjustable Legs

This compact 18-inch heavy-duty gas range combines a 30,000 BTU full hot top with a stainless steel cabinet base for rugged performance and built-in storage.

  • Compact 18-inch width fits tight commercial line spaces without sacrificing heavy-duty output.
  • 30,000 BTU/hr. full hot top delivers powerful high-heat cooking performance.
  • Stainless steel construction is built for durability and easier cleanup.
  • Cabinet base adds storage with a door, universal rack guides, and one removable shelf.
  • 6-inch adjustable stainless steel legs help simplify leveling during installation.

Overall Dimensions:

18.0"W x 36.75"D x 40.5"H

Product Weight:

215.0 lb

30,000 BTU Full Hot Top

Single polished cast iron hot top burner delivers heavy-duty commercial cooking power.

Stainless Steel Construction

Stainless steel front, front top ledge, burner box, sides, base, and stub back are built for durability.

Cabinet Base Storage

Stainless steel cabinet base door, universal rack guides, and one removable shelf provide useful under-range storage.

Heavy-Duty Top Castings

Rugged cast iron top castings are designed for demanding kitchen use.

Individual Pilot And Control

Separate pilot and control for the burner support straightforward operation.

6-Inch Adjustable Stainless Steel Legs

Adjustable legs help level the unit on uneven commercial floors.

Gas Connection Setup

Includes a 1-1/4 inch front gas manifold and a capped 1-1/4 inch rear gas connection.

4-Inch Stainless Steel Stub Riser

Low rear stub riser is included as part of the standard configuration.

Type Heavy Duty Gas Range
Style Full Hot Top
Installation Type Floor Model
Material Stainless Steel
Finish Polished Cast Iron
BTU 30,000 BTU/hr.
Gas Connection Size 1-1/4 Inches
Shipping Width 18 Inches
Shipping Depth 37 Inches
Shipping Height 41 Inches
Shipping Weight 285 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

One-year limited parts and labor

Documents

PDF Cutsheet PDF Download PDF Parts manual PDF Download PDF Service manual PDF Download PDF Sell sheet PDF Download PDF Video PDF Download PDF Installation & operation PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

Natural gas requires 6.0 Inches W.C., and propane requires 10.0 Inches W.C.; a properly sized regulator must be furnished and installed.
Yes. The cabinet base includes a stainless steel door, universal rack guides, and one removable shelf.
The unit measures 18 Inches W x 36.75 Inches D x 40.5 Inches H on 6-inch adjustable legs.
No. A properly sized regulator must be furnished and installed separately; available sizes include 3/4 Inch, 1 Inch, and 1-1/4 Inches.
For combustible surfaces, allow 10 Inches at the rear and sides. Non-combustible surfaces require 0 Inches clearance.
No. It is manufactured for commercial installation only.
