Key specifications

Phase
1-Phase or 3-Phase
Dimensions
36.0"W × 34.0"D × 58.0"H
Type
Range
Style
Hot Top
Installation Type
Floor Model
Material
Aluminized Steel
Spec sheet
Vulcan SKU: EV36S-3HT208

Vulcan EV36S-3HT208 36-Inch Electric Range, 3 Hot Tops

$15,588.00
/each
Estimated to ship in 8–11 business days Free Shipping
Electrical
Included: Vulcan warranty One-year limited parts and labor warranty from the date of original installation

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $1,442/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Specifications

Type Range
Style Hot Top
Installation Type Floor Model
Material Aluminized Steel
Finish Stainless Steel
Usage Commercial
Hot Top Count 3
Hot Top Size 12 in x 24 in
Oven Type Standard Oversized
Oven Input 5 kW
Oven Interior Dimensions 26.5 in W x 26.375 in D x 14 in H
Oven Rack Count 1
Rack Positions 3
Temperature Range 200°F to 500°F
Controls Thermostatic
Voltage 208 Volts
Watts 20 kW
Phase 1-Phase or 3-Phase
Leg Height 6 in

Description

The Vulcan EV36S-3HT208 is a 36-inch electric restaurant range with three thermostatically controlled hot top sections and one standard oversized oven. It is a floor model designed for 208-volt power.

  • Three hot tops: Includes three 12 in x 24 in thermostatically controlled hot top sections.
  • Oversized oven: Includes one standard oversized oven with 5 kW input and top browning control.
  • Temperature control: The oven thermostat adjusts from 200°F to 500°F.
  • Rack included: Includes one oven rack with three rack positions.
  • Stainless steel exterior components: Stainless steel front, sides, back riser, shelf and legs.
  • Adjustable legs: Includes 6 in adjustable legs.
  • Crumb tray: Full-width pull-out stainless steel crumb tray beneath the cooking top.

Overall Dimensions:

36.0"W x 34.0"D x 58.0"H

Product Weight:

440.0 lb

Three Thermostatic Hot Tops

Three 12 in x 24 in thermostatically controlled hot top sections.

Standard Oversized Oven

One standard oversized oven with 5 kW input and top browning control.

Oven Temperature Range

Thermostat adjusts from 200°F to 500°F.

Oven Rack

One oven rack and three rack positions.

Stainless Steel Components

Stainless steel front, sides, back riser, shelf and legs.

Adjustable Legs

6 in adjustable legs.

Pull-Out Crumb Tray

Full-width stainless steel crumb tray located beneath the cooking top.

Welded Frame

Fully MIG welded aluminized steel frame.

Cool-Touch Control Knobs

Control knobs are cool to the touch.

Sheet Pan Fit

18 in x 26 in sheet pans fit side to side and front to back.

Frequently Asked Questions

It has three thermostatically controlled hot top sections, each measuring 12 in x 24 in.
This model requires 208 volts.
The model supports 1-phase or 3-phase power. Ranges ship in 3-phase and are field convertible to single phase.
The range measures 36 in wide by 34 in deep by 58 in high on 6 in adjustable legs.
The oven thermostat adjusts from 200°F to 500°F.
Yes. It includes one oven rack and provides three rack positions.
The range includes one standard oversized oven and one oven rack. Listed accessories are packaged and sold separately.
