Key specifications

Amps
36.1 Amps at 3-Phase; 62.5 Amps at 1-Phase
Phase
1-Phase or 3-Phase
Dimensions
24.0"W × 34.0"D × 58.0"H
Type
Range
Style
Hot Top
Installation Type
Floor Model
Spec sheet
Vulcan SKU: EV24S-2HT240

Vulcan Expando EV24S-2HT240 24-Inch Range, 2 Hot Tops

$12,915.00
/each
Estimated to ship in 8–11 business days Free Shipping
Electrical
Included: Vulcan warranty One-year limited parts and labor warranty from the date of original installation

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $1,195/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Specifications

Type Range
Style Hot Top
Installation Type Floor Model
Material Stainless Steel
Frame Material Aluminized Steel
Finish Stainless Steel Front and Sides
Voltage 240 Volts
Amps 36.1 Amps at 3-Phase; 62.5 Amps at 1-Phase
Watts 15 kW
Phase 1-Phase or 3-Phase
Controls Thermostatic
Temperature Range 200°F to 500°F
Hot Top Count 2
Hot Top Size 12 x 24 in Each
Hot Top Input 5 kW Each
Oven Type Standard
Oven Input 5 kW
Oven Interior Dimensions 20 in W x 26.5 in D x 14 in H
Rack Count 1
Rack Positions 3
Pan Size 18 x 26 in
Leg Height 6 in Adjustable
Crumb Tray Full-Width Pull-Out

Description

The EV24S-2HT240 is a 24-inch electric restaurant range with two thermostatically controlled hot top sections and one standard oven. It requires 240-volt power and supports either 1-phase or 3-phase operation.

  • Hot tops: Two 12 in x 24 in sections with 5 kW input per section.
  • Oven: Standard 5 kW oven with top browning control, one rack, and three rack positions.
  • Construction: Fully MIG-welded aluminized steel frame with stainless steel front, sides, back riser, plate shelf, and 6 in adjustable legs.
  • Temperature control: Thermostat adjusts from 200°F to 500°F, with cool-to-the-touch control knobs.
  • Cleaning: Full-width pull-out stainless steel crumb tray beneath the cooking top.
  • Pan fit: Accepts 18 in x 26 in sheet pans front to back.

Exterior dimensions are 24 in W x 34 in D x 58 in H on 6 in adjustable legs.

Overall Dimensions:

24.0"W x 34.0"D x 58.0"H

Product Weight:

325.0 lb

Two Hot Tops

Includes two 12 in x 24 in thermostatically controlled hot top sections with 5 kW input per section.

Standard Oven

Includes one 5 kW standard oven with top browning control, one rack, and three rack positions.

Thermostatic Controls

Thermostat adjusts from 200°F to 500°F.

Stainless Steel Components

Stainless steel front, sides, back riser, plate shelf, and legs.

MIG-Welded Frame

Fully MIG-welded aluminized steel frame.

Pull-Out Crumb Tray

Full-width stainless steel crumb tray located beneath the cooking top.

Adjustable Legs

Includes 6 in adjustable legs.

Sheet Pan Compatibility

18 in x 26 in sheet pans fit front to back.

Field-Convertible Phase

Shipped in 3-phase configuration and field convertible to single phase.

Frequently Asked Questions

It has two thermostatically controlled 12 in x 24 in hot top sections, each with 5 kW input.
The EV24S-2HT240 requires 240 Volts and supports either 1-phase or 3-phase power. It is shipped in 3-phase configuration and can be field converted to single phase.
The standard oven interior measures 20 in W x 26.5 in D x 14 in H. It includes one oven rack and has three rack positions.
The range measures 24 in W x 34 in D x 58 in H on 6 in adjustable legs.
The thermostat adjusts from 200°F to 500°F.
The product includes a one-year limited parts and labor warranty from the date of original installation, subject to Vulcan's commercial equipment warranty conditions.
