Vulcan Achiever ARS48 48-Inch One-Section Self-Contained Refrigerated Base with 2 Drawers and Marine Edge Stainless Steel Top

Left-Mounted Compressor, 115V, 1-Phase, R-404A

A plug-in refrigerated base that combines cold storage and a durable marine-edge work surface in a compact 48-inch footprint.

  • 48-inch one-section refrigerated base with 2 heavy-duty drawers
  • Holds 4 full-size 12 x 20 x 6 inch pans
  • Self-contained, left-mounted R-404A refrigeration system with 34 to 38 Degrees F operating range
  • Front-breathing design supports zero-clearance installation
  • Stainless steel top, front, sides, and interior with galvanized steel back and bottom
  • Magnetic drawer gaskets, self-closing drawers, and 4-inch casters come standard

Overall Dimensions:

48.0"W x 34.0"D x 26.0"H

Product Weight:

325.0 lb

Marine-Edge Stainless Steel Top

Durable stainless steel work surface with a marine edge to help contain spills.

Two Heavy-Duty Drawers

Two drawers provide refrigerated access below the cooking surface, with self-closing and stay-open functionality.

Four-Pan Drawer Capacity

Each drawer accommodates 12 x 20 x 6 inch pans for a total capacity of 4 pans.

Self-Contained R-404A Refrigeration

Built-in refrigeration system uses a left-mounted compressor, off-cycle defrost, and automatic condensate evaporator.

Front-Breathing Zero-Clearance Design

Front-breathing construction allows installation in tight cookline layouts without rear or side clearance.

INTELA-TRAUL Microprocessor Controls

Water-resistant microprocessor control system with LED display, temperature scale selection, and alarm monitoring.

Magnetic Drawer Seals

Snap-in magnetic drawer gaskets help maintain a tight seal and consistent cabinet temperature.

Heavy-Duty Mobility and Service Access

Includes 4-inch casters in adjustable channels and side, front, and rear access panels for maintenance.

Type Refrigerated Base
Style One-Section
Installation Type Floor Model (With Casters)
Drawer Qty 2
Compressor HP 1/3 HP
BTU 2,440 BTU/HR
Refrigeration Type Self-Contained
Refrigerant Type R-404A
Voltage 115 Volts
Amps 6.7 Amps
Phase 1-Phase
Hertz 60 Hz
Plug Type NEMA 5-15P
Cord Length 9 Feet
Pan Capacity 4
Pan Size 12 x 20 x 6 Inches
Controls Microprocessor
Temperature Range 34 to 38 Degrees F
Material Stainless Steel
Interior Finish Stainless Steel
Selling Unit Each
Units Per Case 1
Shipping Weight 430 lb.

Warranty & Protection

3-year parts and labor; 2 additional years on compressor parts

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It has 2 heavy-duty drawers.
Each drawer accommodates 12 x 20 x 6 inch pans.
It requires 115V/60/1 power, draws 6.7 amps, and includes a NEMA 5-15P plug with a 9-foot cord.
The standard operating temperature is 34 to 38 Degrees F.
Yes. The front-breathing design allows zero-clearance installation.
The unit includes a three-year parts and labor warranty plus two additional years of compressor parts coverage.
