Vulcan QuickFry™ 3VHG70AF 3-Vat Gas Fryer, 70 lb Capacity per Vat, Stainless Steel

SKU: 3VHG70AF
$42,812.00
Free Shipping
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Vulcan QuickFry™ 3VHG70AF is a commercial three-vat gas fryer with 70 lb capacity per vat. It features solid-state analog knob control with melt cycles, electronic ignition, and a built-in KleenScreen PLUS® filtration system.

The fryer has stainless steel cabinets and fry tanks, twin fry baskets, adjustable casters, and a 330,000 BTU/hr gas input. Electrical requirements are 120 V, 50/60 Hz, single phase.

  • Control: Solid-state knob control with digital character display behind the access panel
  • Filtration: Built-in KleenScreen PLUS® system with one-touch pump operation
  • Construction: Stainless steel cabinet and fry tanks
  • Mobility: Adjustable casters with two swivel locking and two non-locking casters

Overall Dimensions:

58.69"W x 33.5"D x 47.75"H

Product Weight:

717.0 lb

Three 70 lb fry vats

Provides three fry tanks with 70 lb oil capacity per vat.

Solid-state knob control

The VHG70AF control includes a solid-state knob, a digital character display behind the access panel, a 150–390°F temperature range, and three melt modes.

KleenScreen PLUS filtration

The built-in filtration system includes a stainless steel filter pan and one-touch pump operation at 8 gal/min at 60 Hz.

Electronic ignition

Uses electronic matchless ignition.

Stainless steel construction

Includes a stainless steel cabinet and stainless steel fry tanks.

Adjustable casters

Includes 6 in adjustable casters with two swivel locking and two non-locking casters.

Twin fry baskets

Standard equipment includes twin fry baskets with plastic-coated handles.

ENERGY STAR

The exact product is identified as ENERGY STAR.

Related Searches

Best Sellers Commercial Fryers Cooking Equipment Digital Kitchen Timers Equipment Fryers Gas Fryers Kitchen Timers & Food Thermometers New Arrivals Smallwares Vulcan
Fry vats 3 tanks
Capacity per vat 70 lb
Frying area per vat 18 1/8 in x 14 1/8 in
Oil depth 4 1/2 in
Control type Solid-state analog knob control
Temperature range 150–390°F (66–199°C)
Melt modes 3
Filtration system KleenScreen PLUS® built-in filtering system
Filter pan capacity 90 lb frying compound
Filter area 462 sq in
Filter pump rate 8 gal/min at 60 Hz
Filter motor 1/3 HP
Gas input 330,000 BTU/hr total for natural gas; 110,000 BTU/hr per vat natural gas and 100,000 BTU/hr per vat propane
Electrical requirements 120 V, 50/60 Hz, 1 phase
Electric current 7.5 A
Gas connection 1 1/4 in NPT-F rear connection
Construction Stainless steel cabinet and fry tank
Casters 6 in adjustable casters; 2 swivel locking and 2 non-locking
Basket configuration Twin fry baskets

Certifications & Compliance

Certified badge of Energy Star Certified
Energy Star Certified
Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

One-year limited parts and labor warranty; the stainless steel fry tank has a 10-year limited warranty.

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The fryer has three vats, each with a 70 lb oil capacity.
It uses solid-state analog knob control with a digital character display behind the access panel, a 150–390°F temperature range, and three melt modes.
Yes. It includes a built-in KleenScreen PLUS® filtration system with a 90 lb filter pan, 462 sq in filter area, and an 8 gal/min pump rate at 60 Hz.
The fryer requires 120 V, 50/60 Hz, single-phase power and is listed at 7.5 A.
The product measures 58 11/16 in wide, 33 1/2 in deep, and 47 3/4 in high.
Yes. Twin fry baskets with plastic-coated handles are standard equipment.
Natural gas and propane gas are documented. The cutsheet lists 110,000 BTU/hr per vat for natural gas and 100,000 BTU/hr per vat for propane.
The product is listed with CSA, ENERGY STAR, and NSF.
