Vulcan

Vulcan 3GR45MF 3-Battery Gas Floor Fryer with Built-In KleenScreen Plus Filtration

SKU: 3GR45MF
$35,204.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Digital Kitchen Timers Fryers Gas Fryers Kitchen Timers & Food Thermometers New Arrivals Smallwares Vulcan

Vulcan 3GR45MF 3-Battery Gas Floor Fryer with Built-In KleenScreen Plus Filtration

Millivolt Controls, 45-50 lb. Vats, Stainless Steel

Built for high-volume frying, this three-vat gas fryer combines millivolt simplicity, built-in filtration, and stainless steel durability in one heavy-duty floor unit.

  • Three-battery gas fryer with 45-50 lb. capacity per vat for high-volume service
  • KleenScreen Plus built-in filtration helps keep oil cleaner and cleanup simpler
  • Millivolt thermostat controls provide straightforward, dependable temperature management
  • Stainless steel cabinet and fry tank are built for demanding commercial use
  • Twin baskets and adjustable casters add convenience and mobility
  • 360,000 BTU output supports quick heat recovery during peak periods

Overall Dimensions:

46.5"W x 30.13"D x 46.25"H

Product Weight:

695.0 lb

Three-Battery Fryer Design

Three separate vats support high-volume production and batch frying.

Built-In KleenScreen Plus Filtration

Integrated filtration helps remove sediment and extend oil life.

Millivolt Thermostat Controls

Reliable millivolt controls keep operation simple.

Stainless Steel Construction

Stainless steel cabinet and fry tank improve durability and cleanup.

1/3 HP Filter Motor and Pump

Circulates frying compound at 8 gallons per minute for efficient filtration.

Twin Baskets Included

Allows multiple menu items or larger batches to be fried efficiently.

Adjustable Casters

6-inch casters include 2 swivel locking and 2 non-locking wheels.

360,000 BTU Output

High heat output supports fast recovery in busy kitchens.

Type Fryer
Style Battery
Installation Type Floor Model
Compartments 3
Pan Capacity 45-50 lb. Per Vat
Controls Millivolt Thermostat
Material Stainless Steel
BTU 360,000 BTU
Voltage 120 Volts
Amps 6 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Gas Connection Size 1 1/4 Inches NPT
Selling Unit Each
Units Per Case 1
Shipping Width 47 Inches
Shipping Depth 31 Inches
Shipping Height 47 Inches
Shipping Weight 695 lb.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1-year limited parts and labor; 10-year limited fry tank warranty.

Documents

PDF Cutsheet PDF Download PDF Brochure PDF Download PDF Owner's manual PDF Download PDF Warranty PDF Download PDF Parts list PDF Download PDF Video PDF Download PDF Sell sheet PDF Download PDF Service manual PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The built-in filter system requires 120 volt, 60 Hz, 1-phase power and uses a NEMA 5-15P plug.
It uses a 1 1/4-inch NPT common rear gas connection.
Each vat has a 45-50 lb. capacity.
The fryer includes a 1-year limited parts and labor warranty and a 10-year limited fry tank warranty.
Yes. The documentation says to specify Natural Gas or Propane when ordering.
The system includes a stainless steel filter pan, mesh filter screen, tank brush, clean-out rod, and high-temperature discard hose.
