Vollrath  |  SKU: FC-4DH-06208-I

Vollrath FC-4DH-06208-I Steam Tables & Food Wells

$4,100.70
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Vollrath FC-4DH-06208-I Six-Well Dry Hot Drop-In

Waterless electric food well with individual infinite controls

Keep six menu items fresh, safe and perfectly hot—without the hassles of water or hard-wiring. Designed and built in the USA, this Vollrath modular drop-in installs fast, fits flush and delivers reliable performance service after service.

Key features

  • Six independent, waterless wells—no refilling, no drain lines, zero lime-scale buildup
  • 300-series stainless-steel top flange & drawn wells for maximum durability and easy cleaning
  • Open-element design heats quickly; 750-1000 W per well (total 4 500-6 000 W)
  • Individual infinite controls & power indicator lights on a stainless remote panel (4 ft tether)
  • Fully insulated on all sides—including between wells—for energy efficiency & cooler surfaces
  • Accepts full-size or fractional pans up to 6 in (15.2 cm) deep Adapter bars recommended for fractional pans; not for use with plastic pans.
  • Zero-clearance, top-mount installation—no trim ring needed, even in non-metallic countertops
  • Ships with factory-installed 6 ft (1.8 m) cord & NEMA 6-50P plug—no field wiring
  • Includes gasket & mounting clips for counters up to 3 in (7.6 cm) thick
  • NSF 4 & cULus listed; made to order in Sheboygan, WI, USA

Specifications

Model FC-4DH-06208-I
Operation Dry (waterless), electric
Wells / Controls 6 wells  |  Infinite rotary controls, independent
Heating Power 750 – 1000 W per well (4 500 – 6 000 W total)
Electrical 208-240 V / 60 Hz / 1-phase, 21.6 – 25 A, factory-installed cord with NEMA 6-50P
Overall (W × D × H) 81 1⁄4 in × 26 in × 15 in (206.4 cm × 66 cm × 38.1 cm)
Counter Cut-out 80 1⁄2 in × 25 1⁄4 in (204.5 cm × 64.1 cm)
Control-Panel Cut-out 26 1⁄4 in × 3 5⁄16 in (66.7 cm × 8.4 cm)
Pan Capacity Six full-size pans (12 × 20 in) up to 6 in deep Adapter bars available for fractional pans (item 19186).
Approvals NSF 4, cULus
Country of Origin USA
Warranty Standard 1-year parts & labor see full policy

Installation & use

  • Suitable for indoor, commercial food-service environments
  • Mount flush to countertop using included gasket and clips—no side or rear clearance required
  • Plug into a dedicated 208-240 V / 50 A receptacle; do not modify the cord or plug
  • Preheat wells before loading food; maintain safe food temperatures (> 140 °F / 60 °C)
Made to order: Drop-in units are custom-built and cannot be canceled or returned. Please verify dimensions, electrical requirements and countertop compatibility before ordering.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, cULus, Made in USA

Height

15.0in

Width

81.25in

Depth

26.0in

Shipping Weight

222.0lbs

Style

individual pans

Controls

infinite controls

Wet or Dry operation

dry

Drain

without drain

Insulated or Non-Insulated

insulated

Pan Capacity

(6) full size (12" x 20")

Construction

stainless steel construction

Specifications

Hot Food Well Drop-In Unit, electric, dry operation only, (6) well, infinite control, 81-1/4"W x 26"D x 15"H, stainless steel remote control panel, includes mounting clips, 208-240/60/1-ph, 750-1000 watts per well, 21.6-25 amps, cord with NEMA 6-50 plug, NSF, cULus, Made in USA, (made to order) (Refer to vollrathfoodservice.com for full warranty policy)
