Vollrath  |  SKU: FC-4DH-03208-T

Vollrath FC-4DH-03208-T Steam Tables & Food Wells

$2,601.35
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Vollrath FC-4DH-03208-T 3-Well Dry Hot Drop-In

Thermostatic • 208-240 V • Waterless Operation

Create a high-performance serving station—no plumbing, drain lines or trim rings required. The Vollrath FC-4DH-03208-T drop-in holds three full-size pans with precise thermostatic control, installs flush into virtually any countertop, and plugs into a standard NEMA 6-20 receptacle for true plug-and-play convenience.

Key Benefits
  • Waterless design speeds heat-up and eliminates scale, lime and drain maintenance.
  • Independent thermostatic controls and power lights for each well.
  • Remote 300-series stainless-steel control panel with 4 ft (121.9 cm) tether for flexible mounting.
  • 300-series stainless flange & drawn wells; stainless shroud protects moisture-resistant open elements.
  • Fully insulated on all sides—including between wells—for energy efficiency and cooler counters.
  • Accepts full-size or fractional pans up to 6 in (15.2 cm) deep (adapter bars recommended when using fractional pans; not for plastic pans).
  • Zero-clearance top-mount installation; gasket and mounting clips (for counters ≤ 3 in / 7.6 cm) included.
  • NSF 4 and cULus listed; Made in the USA.
Specifications
Item number FC-4DH-03208-T
Number of wells 3 (full-size)
Control type Thermostatic, one per well
Operation Dry (waterless)
Overall size (W × D × H) 41.5 in × 26 in × 15 in (105.4 × 66 × 38.1 cm)
Countertop cut-out 40.75 in × 25.25 in (103.5 × 64.1 cm)
Control panel size 15 in × 3 5⁄16 in (38.1 × 8.4 cm)
Power per well 750 – 1000 W
Total power / current 2250 – 3000 W • 10.8 – 12.5 A
Electrical 208 – 240 V • 60 Hz • 1-phase
Plug type NEMA 6-20P (factory-installed 6 ft / 1.8 m cord)
Construction 300-series stainless steel wells & flange; insulated cabinet
Certifications NSF 4, cULus
Origin Made in USA
Warranty Standard one-year limited warranty (see full policy)
Ideal For
  • Buffet lines & cafeterias
  • QSR and fast-casual build stations
  • Hotels, convention centers and catered events
  • Anywhere plumbing access is limited or costly
Made-to-Order: This drop-in is built to order and cannot be cancelled or returned. Indoor use only.

Need help specifying cut-out dimensions, adapter bars or other accessories? Our equipment specialists are happy to assist—contact us before ordering.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, cULus, Made in USA

Height

15.0in

Width

41.5in

Depth

26.0in

Shipping Weight

117.0lbs

Insulated or Non-Insulated

insulated

Drain

without drain

Pan Capacity

(3) full size (12" x 20")

Style

individual pans

Controls

thermostatic controls

Wet or Dry operation

dry

Construction

stainless steel construction

Specifications

Hot Food Well Drop-In Unit, electric, dry operation only, (3) well, thermostatic control, 41-1/2"W x 26"D x 15"H, stainless steel remote control panel, includes mounting clips, 208-240/60/1-ph, 750-1000 watts per well, 10.8-12.5 amps, cord with NEMA 6-20 plug, NSF, cULus, Made in USA, (made to order) (Refer to vollrathfoodservice.com for full warranty policy)
