Vollrath FC-4DH-03120-T Steam Tables & Food Wells
Description
Vollrath FC-4DH-03120-T 3-Well Dry Hot Food Drop-In
120 V | Thermostatic controls | 1000 W per well | Made in USAKeep entrées and sides hot without the hassle of water management. The Vollrath FC-4DH-03120-T is a waterless, three-well drop-in that installs flush in virtually any counter, delivers precise thermostatic heat, and plugs into a standard 120-volt NEMA 5-50 outlet—no hard-wiring required.
Why You’ll Love It
- Waterless design – no drains, heaters or refills to manage.
- (3) full-size wells accept pans up to 6″ (15.2 cm) deep; adapter bars recommended for fractional pans.
- Individual thermostatic controls with power indicator lights for each well.
- Open-element heating with moisture-resistant stainless steel shroud for rapid response and easy clean-up.
- Zero-clearance top-mount installation; fits counters up to 3″ (7.6 cm) thick with included gasket & clips.
- Remote stainless steel control panel on a 4′ (122 cm) tether lets you mount controls exactly where you need them.
- Fully insulated on all non-exposed sides—including between wells—for cooler counter surfaces and energy efficiency.
- 6′ (1.8 m) cord & NEMA 5-50P plug—just drop in, tighten the clips, and power on.
- NSF & cULus Listed for safe, sanitary commercial use.
- Fabricated, tested and shipped from Sheboygan, Wisconsin.
Technical Specs
| Model No. | FC-4DH-03120-T |
|---|---|
| Wells / Capacity | 3 wells | accommodates (3) 12″ x 20″ pans up to 6″ deep |
| Operation | Dry (waterless) |
| Control Type | Thermostatic, independent for each well |
| Voltage / Phase | 120 V / 60 Hz / 1-ph |
| Wattage | 1000 W per well (3000 W total) |
| Amperage | 25.0 A |
| Plug | NEMA 5-50P (6′ cord) |
| Overall Dimensions | 41 1/2″ W × 26″ D × 15″ H |
| Counter Cutout | 40 3/4″ W × 25 1/4″ D |
| Control Panel Cutout | 15″ W × 3 5/16″ H |
| Construction | 300-series stainless steel well & flange; stainless control panel & element shroud |
| Certifications | NSF, cULus |
| Warranty | 1-year limited (see VollrathFoodservice.com for full policy) |
| Country of Origin | USA |
What’s in the Box
- (1) FC-4DH-03120-T drop-in with factory-installed 6′ power cord
- Remote stainless steel control panel (pre-wired)
- Mounting gasket & standard mounting clips
- User & installation manual
Not for use with plastic pans. Sheet-pan adapter (Vollrath #19186) sold separately.
