Vollrath  |  SKU: FC-4DH-01120-I

Vollrath FC-4DH-01120-I Steam Tables & Food Wells

$1,145.70
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Vollrath Dry Hot Drop-In Food Well – 1 Well, 120 V, Infinite Control

Model FC-4DH-01120-I

Keep menu items hot and appetizing without the hassles of water or hard-wiring. Vollrath’s made-in-USA dry drop-in well slips neatly into your counter cut-out, plugs into a standard 120 V outlet, and delivers reliable 1000-watt performance for a single full-size pan.

Key Features

  • Waterless design – eliminates plumbing, limescale and drainage concerns.
  • 300-series stainless steel flange & drawn well for superior durability and easy cleanup.
  • Open-element heater provides fast, even heat while saving energy.
  • Infinite manual control knob with power indicator light for precise temperature holding.
  • Remote stainless steel control panel on a 4 ft (121.9 cm) tether for flexible mounting.
  • Fully insulated on all sides to maximize efficiency and protect surrounding surfaces.
  • Zero-clearance installation – drops into non-metallic countertops without trim rings.
  • Accepts full-size 12" × 20" pans or fractional pans up to 6" (15.2 cm) deep (adapter bars recommended for fractional pans).
  • Standard 6 ft (1.8 m) cord with NEMA 5-15P plug – no electrician required.
  • Includes gasket and mounting clips for counters up to 3" (7.6 cm) thick.
  • NSF & cULus listed; proudly made in the USA.

Perfect For

  • Buffet and cafeteria lines
  • Quick-service or fast-casual restaurants
  • Convenience stores and micro-markets
  • Catering or banqueting drop stations

Specifications

Item number FC-4DH-01120-I
Capacity (1) full-size 12" × 20" pan (or fractional equivalents) up to 6" deep
Operation Dry – waterless
Control type Infinite manual dial
Overall dimensions (W × D × H) 15" × 26" × 15" (38.1 × 66 × 38.1 cm)
Counter cut-out 14 ¼" × 25 ¼" (36.2 × 64.1 cm)
Electrical 120 V / 60 Hz / 1-phase, 1000 W, 8.3 A
Plug type NEMA 5-15P (6 ft cord included)
Construction 300-series stainless steel well & flange; insulated cabinet
Certifications NSF, cULus
Country of origin USA
Warranty 1-year limited (see VollrathFoodservice.com for full policy)
Made-to-Order: This drop-in is produced on demand and cannot be canceled or returned after the order is placed.

Indoor use only. Not for use with plastic pans. Room temperature and HVAC conditions can affect holding performance.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, cULus, Made in USA

Height

15.0in

Width

15.0in

Depth

26.0in

Shipping Weight

35.0lbs

Controls

infinite controls

Style

individual pans

Pan Capacity

(1) full size (12" x 20")

Wet or Dry operation

dry

Drain

without drain

Insulated or Non-Insulated

insulated

Construction

stainless steel construction

Specifications

Hot Food Well Drop-In Unit, electric, dry operation only, (1) well, infinite control, 15"W x 26"D x 15"H, stainless steel remote control panel, includes mounting clips, 120/60/1-ph, 1000 watts, 8.3 amps, cord with NEMA 5-15 plug, NSF, cULus, Made in USA, (made to order) (Refer to vollrathfoodservice.com for full warranty policy)
