Vollrath  |  SKU: FC-4C-03120-FA

Vollrath FC-4C-03120-FA Steam Tables & Food Wells

$6,162.76
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Parts diagram Wiring diagram Owner's manual Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Vollrath 3-Well Forced-Air Refrigerated Drop-In Cold Food Well

Model FC-4C-03120-FA  |  Self-Contained  |  120 V

Keep salads, deli toppings and cold entrées safely chilled and beautifully displayed. Vollrath’s U.S-built forced-air drop-in blankets every pan with an even curtain of cold air, so product stays fresh and appetizing through the busiest rush.

Why you’ll love it

  • Dual forced-air flow cools from both sides for consistent, NSF-7 compliant temperatures.
  • Eco-conscious R513A refrigerant – non-flammable & low global-warming potential.
  • 18-ga 300-series stainless steel top with full-perimeter drip edge and molded breaker gasket.
  • Seamless stainless interior well cleans quickly and resists corrosion.
  • Shallow 3" recess maximises product visibility for higher impulse sales.
  • Remote on/off switch (4 ft cord) mounts to any cabinet side for easy access.
  • Self-contained 1/3 HP system ships ready to plug into a standard NEMA 5-15R outlet – no hard-wiring.
  • Accepts full or fractional pans up to 7" deep; positioning clips included.
  • ¾" integral drain speeds clean-up at day’s end.
  • Made in USA • cULus & NSF listed.

Technical specs

Pan capacity 3 full-size 12" × 20" pans (up to 7" deep)
Overall dimensions 41 ½" W × 25 ¼" D × 28 ⅝" H (105.4 × 64.1 × 72.7 cm)
Recommended cut-out 40 ¾" W × 24" D
Verify on unit before cutting countertop.
Refrigeration Forced air, self-contained, R513A
Compressor 1/3 HP • 4 800 BTU/h heat rejection
Electrical 120 V / 60 Hz / 1-ph • 6 A • 6 ft cord with NEMA 5-15P plug
Construction 18-ga 300-series stainless top & well • 18-ga galvanized exterior
Drain ¾" integral drain fitting
Listings NSF 7, cULus
Origin Made in USA

Installation & operating tips

  • Zero side clearance required; maintain 3" (7.6 cm) at condenser air inlets/outlets.
  • Provide at least 80 in² (516 cm²) each for fresh-air intake and exhaust venting.
  • Designed for indoor environments ≤ 86 °F (30 °C) and ≤ 60 % RH.
  • Use adapter bars/templates so pan tops sit 1" below unit rim for proper cold-air curtain.
Made-to-order: Vollrath drop-ins cannot be canceled or returned. Contact Vollrath for current lead time.

Warranty: 1 year parts & labor + 4 additional years on the compressor.
Full details at vollrathfoodservice.com.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, cULus, Made in USA

Height

28.63in

Width

41.5in

Depth

26.0in

Shipping Weight

189.0lbs

Pan Qty

3-pan

Width (side - side)

37 - 42 inches

Layout

deep

Style

self-contained refrigeration

Insulation

insulated

Finish

stainless steel & galvanized steel

Pan Size

full-size (12" x 20")

Specifications

Refrigerated Cold Food Well Unit, drop-in, 3-well, 41-1/2"W x 25-1/4"D x 28-5/8"H, (overall), holds pans up to 7" deep, dual forced air cooled, remote mounted on-off switch,18/300 series stainless steel top & interior well, galvanized exterior, self-contained refrigeration, 3/4" integral drain, includes positioning clips, 1/3 HP, 120v/60/1-ph, 6.0 amps, NEMA 5-15P, cULus, NSF, Made in USA (contact Vollrath for lead time) (Refer to vollrathfoodservice.com for full warranty policy)
