Vollrath

Vollrath Signature Lemon Drop Full-Size 20-Compartment X-Tall Glass Rack — 19-3/4 in W x 19-3/4 in D x 8-1/2 in H

SKU: 5270615
$223.35
/each
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Bar Equipment Best Sellers Dishwashers New Arrivals Undercounter Dishwashers Undercounter Dishwashers Vollrath

Vollrath Signature Lemon Drop Full-Size 20-Compartment X-Tall Glass Rack — 19-3/4 in W x 19-3/4 in D x 8-1/2 in H

Polypropylene Lemon Drop design; light green body with gold top extender; NSF listed; Made in USA

Open polypropylene Lemon Drop rack protects glassware, maximizes wash and drying performance, and fits taller stemware with an X‑Tall 7-1/8 in compartment height.

  • 20 individual compartments, each 3-15/16 in diameter, reduce chipping and breakage.
  • X-Tall configuration provides 7-1/8 in usable compartment height for taller glassware.
  • Open grid design promotes thorough washing, complete rinsing, rapid drying and quick glass cooling.
  • Durable polypropylene construction; NSF listed and manufactured in the USA.
  • Sold in cases of 3; made-to-order (non-returnable). Custom screen imprinting available.

Overall Dimensions:

19.75"W x 19.75"D x 8.5"H

Product Weight:

7.0 lb

Open Wash‑Friendly Design

Open grid promotes thorough washing action, complete rinsing, rapid drying and quick glass cooling for spot‑free glassware.

Individual Compartments

20 molded compartments isolate glassware to minimize contact, preventing chipping and breakage during wash and storage.

X‑Tall Capacity

Overall height 8-1/2 in with 7-1/8 in inside compartment height to accommodate taller stemware.

Compartment Size

Each compartment measures 3-15/16 in diameter (approx. 10 cm) to fit a wide range of glasses.

Durable Construction

Made from high-quality polypropylene for strength, chemical resistance and long service life in commercial dishrooms.

Signature Lemon Drop Pattern

Lemon Drop design (Pat. No. D650,541) improves airflow and drying performance.

NSF Listed & Made in USA

NSF certified; manufactured in the United States.

Custom Imprinting Available

Custom screen imprinting is supported—see Vollrath imprint guide or contact customer service to submit artwork and order.

Made to Order / Return Policy

Racks are made to order and cannot be returned.

Type Compartment Glass Rack
Style Full Size
Material Polypropylene
Compartments 20
Max Glass Diameter 3-15/16 Inches
Maximum Glass Height 7-1/8 Inches
Color Light Green with Gold Top Extender
Selling Unit Each
Units Per Case 3
Shipping Width 20 Inches
Shipping Depth 20 Inches
Shipping Height 9 Inches
Shipping Weight 7.0 lb.
Country of Origin USA

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Warranty & Protection

Refer to vollrathfoodservice.com for full warranty policy.

Documents

PDF Catalog page PDF Download PDF Product guide PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

Overall dimensions are 19-3/4 in W x 19-3/4 in D x 8-1/2 in H. Each compartment is 3-15/16 in in diameter with a 7-1/8 in inside height.
Yes — this rack is NSF listed and manufactured in the USA.
Yes. Vollrath offers custom screen imprinting (see the Signature Warewashing Rack Imprint Guide). Follow the imprint form instructions and contact Vollrath customer service to submit artwork and place the order.
Units are packed in cases of 3. Racks are made to order and cannot be returned.
The X‑Tall configuration provides 7-1/8 in of usable compartment height — suitable for many taller glasses. For taller items, review taller height variants before ordering.
