Vollrath 3665120 Steam Tables & Food Wells
$3,191.90
Unit price
/
Unavailable
Description
Vollrath 4-Well Short Side Hot Drop-In, Infinite Controls & Manifold Drain
Model 3665120 • 1000 W per well (4000 W total)Get the holding power of four full-size steam-table pans without giving up valuable counter depth. Vollrath’s Short Side Hot Drop-In rotates each pan sideways, creating an ultra-slim 18" front-to-back footprint that brings food closer to guests and servers for faster, safer service.
Key benefits
- Narrow 18" presentation turns full-size pans sideways for easy reach & space savings.
- Four individually infinite-controlled wells let you fine-tune holding temperatures.
- 18/8 stainless-steel top flange & drawn wells resist corrosion and clean up fast.
- Thick polyurethane foam insulation on all sides – including between wells – locks in heat and cuts energy costs.
- 1" copper manifold drain with individual ½" ball valves plus master shut-off; drain plug included.
- Full-perimeter drip edge and supplied gasket keep moisture off the counter.
- 6 ft factory-installed cord with NEMA 6-30P plug; no hard-wiring required.
- Remote stainless control panel (4 ft tether) with power lights for flexible mounting.
- Zero-clearance, top-mount design for simple drop-in installation; mounting clips included.
- UL, CUL & NSF listed; proudly Made in the USA.
Technical specifications
| Wells / Capacity | 4 full-size (12" x 20") pans, up to 6" deep |
|---|---|
| Total Wattage | 4000 W (1000 W per well) |
| Voltage / Phase | 208 – 240 V / 60 Hz / 1-ph |
| Amperage | 14.4 – 16.7 A |
| Plug | NEMA 6-30P, 6 ft cord |
| Controls | 4 independent infinite controls with indicator lights |
| Well Size (each) | 20" L x 12" W x 8" D |
| Overall Dimensions | 88-1/4" W x 18" D |
| Countertop Cut-out | 87-1/2" W x 17-1/4" D, 7/8" corner radius |
| Construction | 18/8 stainless steel, foam insulated |
| Drain | 1" manifold with ½" ball valves & master shut-off |
| Certifications | UL, CUL, NSF |
| Country of Origin | United States |
Compatible accessories
- Adapter bars for fractional pans (recommended when using 1/3, 1/6, etc.).
- Sheet-pan adapter (Item #19186) for versatile menu layouts.
Important:
- This drop-in is designed for wet (moist) operation only; add water to each well for even heating and to meet NSF-4 requirements.
- Modular drop-ins are built to order and cannot be canceled or returned.
- Refer to vollrathfoodservice.com for complete warranty policy.
Features & Specs
Features & Specs
Manufacturer
Vollrath
Certifications
NSF, UL, Made in USA
Height
21.5in
Width
88.56in
Depth
18.0in
Shipping Weight
218.0lbs
Controls
infinite controls
Style
individual pans
Construction
stainless steel construction
Insulated or Non-Insulated
insulated
Pan Capacity
(4) full size (12" x 20")
Drain
with drain
Wet or Dry operation
wet
Specifications
Short Sided Hot Well, Drop-In, (4) pan, infinite controls, manifold drain, 4000 watts, 208-240v/60/1-ph, 14.4-16.7 amps, NEMA 6-30P, turns full size pans sideways for more narrow presentation & easy reach, 18/8 stainless steel, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 88-1/4" x 18", cutout dimensions 87-1/2" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
