Vollrath  |  SKU: 3665030

Vollrath 3665030 Steam Tables & Food Wells

$4,276.40
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

4-Well Short Side Hot Drop-In with Auto-Fill & Manifold Drain

Vollrath Model 3665030 · 1000 W per well (4 kW total)

Turn full-size steam table pans sideways for an ultra-narrow, operator-friendly footprint without giving up capacity. Vollrath’s U.S-built Short Side Hot Drop-In keeps four pans of menu items hot, fresh and within easy reach—ideal for buffets, serving lines, kiosks or anywhere counter depth is at a premium.

Why you’ll love it

  • Space-saving 18 inch depth delivers a clean, narrow presentation and improved reach.
  • Auto-fill maintains the correct water level automatically—no babysitting required.
  • 1 inch copper manifold drain with master shut-off plus individual ½ inch ball valves for fast, mess-free clean-up.
  • Independent thermostatic controls and power lights for each well ensure accurate holding temperatures.
  • 18/8 stainless-steel top flange and drawn wells resist corrosion and wipe clean easily.
  • Thick polyurethane foam insulation on every side (and between wells) maximizes efficiency.
  • Full-perimeter drip edge and included gasket protect your counter from condensate.
  • Ships with a 6 ft (1.8 m) cord and NEMA 6-30P plug—no hard-wiring required.
  • Made in the USA and listed to UL, CUL and NSF standards.

Specifications

Pan Capacity (4) Full-size steam table pans — accepts pans up to 6 in (15.2 cm) deep
Well Interior (each) 20 in L × 12 in W × 8 in D (50.8 × 30.5 × 20.3 cm)
Overall Dimensions 88 ¼ in L × 18 in D (224.2 × 45.7 cm)
Counter Cut-Out 87 ½ in L × 17 ¼ in D with ⅞ in corner radius
Electrical 208-240 V / 60 Hz / 1-ph, 14.4-16.7 A, 4000 W, NEMA 6-30P
Controls Remote stainless-steel panel (4 ft tether) with individual thermostats & indicator lights
Drain System 1 in copper manifold, master shut-off, individual ½ in ball valves, drain plug included
Construction 18/8 stainless steel, polyurethane foam insulated
Agency Listings UL, CUL, NSF
Country of Origin Made in USA

Included

  • 6 ft power cord with NEMA 6-30P plug
  • Remote control panel and mounting clips (for counters up to 3 in / 7.6 cm thick)
  • Gasket for under-counter drip edge
  • Drain plug

Recommended Accessories

  • Adapter bars for fractional pans (sold separately)
  • Sheet pan adapter – Item #19186
Important: This drop-in is designed for moist-heat operation; always keep water in the wells to meet NSF 4 performance standards and avoid element damage. Orders for drop-ins cannot be canceled or returned once placed.

For complete warranty terms, visit vollrathfoodservice.com.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, UL, Made in USA

Height

21.5in

Width

88.56in

Depth

18.0in

Shipping Weight

362.0lbs

Style

individual pans

Controls

thermostatic controls

Insulated or Non-Insulated

insulated

Construction

stainless steel construction

Pan Capacity

(4) full size (12" x 20")

Drain

with drain

Wet or Dry operation

wet

Specifications

Short Sided Hot Well, Drop-In, (4) pan, thermostatic controls, autofill & manifold drain, 4000 watts, 208-240v/60/1-ph, 14.4-16.7 amps, NEMA 6-30P, turns full size pans sideways for more narrow presentation & easy reach, 18/8 stainless steel, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 88-1/4" x 18", cutout dimensions 87-1/2" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
