Vollrath 3665020 Steam Tables & Food Wells
Description
Vollrath Short-Side Hot Well Drop-In – 4 Pan, Thermostatic, Manifold Drain
Model 3665020 | 1000 W per well (4 000 W total)Give guests easier access and reclaim valuable counter depth with this Made-in-USA short-side drop-in from Vollrath. Four full-size steam-table pans are rotated sideways, creating a slim 18-inch presentation that is perfect for cafés, kiosks and serving lines where space and reach matter.
Key features
- Space-saving design turns 12 × 20 in pans sideways for an 18 in counter footprint.
- Thermostatic controls (one per well) accurately maintain food-safe holding temperatures.
- 1 in copper manifold drain with master shut-off drains all wells quickly; drain plug included.
- 18/8 stainless-steel top flange & drawn wells resist corrosion and clean up fast.
- Thick polyurethane-foam insulation on all sides—including between wells—for maximum efficiency.
- Full-perimeter drip edge & included gasket protect counters from moisture.
- Remote stainless control panel with 4 ft tether and power light for each well.
- Zero-clearance installation; supplied mounting clips fit counters up to 3 in thick.
- 6 ft cord with NEMA 6-30P plug – no hard-wiring required.
- UL, CUL & NSF listed; wet operation meets NSF 4 performance standards.
Specifications
| Item number | 3665020 |
|---|---|
| Pan capacity | 4 full-size (12 × 20 in) or fractional pans up to 6 in deep† |
| Control type | Thermostatic (1 per well) |
| Drain style | 1 in manifold drain with master shut-off & plug |
| Total wattage | 4 000 W (1 000 W per well) |
| Electrical | 208-240 V, 60 Hz, 1-phase, 14.4-16.7 A |
| Plug | NEMA 6-30P (factory installed) |
| Overall dimensions | 88 ¼ in L × 18 in W |
| Counter cut-out | 87 ½ in L × 17 ¼ in W (7⁄8 in corner radius) |
| Individual well size | 20 × 12 in; 8 in deep |
| Construction | 18/8 stainless steel with polyurethane insulation |
| Certifications | UL, CUL, NSF |
| Country of origin | USA |
† Adapter bars (sold separately) are recommended when using fractional pans.
For complete warranty information, visit vollrathfoodservice.com.
