Vollrath  |  SKU: 36646HD

Vollrath 36646HD Steam Tables & Food Wells

$2,386.35
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Vollrath 36646HD Short-Side Modular Hot Well Drop-In – 2 Pans

Marine-grade wells • thermostatic controls • standard drains • 208-240 V

Give your serving line a slimmer footprint without sacrificing capacity. The Vollrath 36646HD turns two full-size pans sideways, fitting an 18-inch counter depth while keeping food at safe, appetizing temperatures. Built from corrosion-proof 316 stainless and shipped ready to plug in, this drop-in hot well is the easy, durable way to maximize space.

Key features

  • Short-side orientation reduces front-to-back depth to just 18" for narrow counters and easy reach.
  • (2) full-size wells (20" × 12" × 8") – accepts pans up to 6" deep; fractional pans with adapter bars.
  • 18-gauge SAE 316 marine-grade stainless steel top for superior corrosion resistance.
  • Thick polyurethane foam insulation on all sides, including between wells, for energy efficiency.
  • Remote stainless control panel on a 4' tether with individual thermostatic knobs and indicator lights.
  • Standard ½" NPT drains with ball valves; drain plugs included for quick, mess-free cleanup.
  • Full-perimeter drip edge and included gasket protect your countertop from moisture.
  • 6' cord with NEMA 6-15P plug – no hard-wiring required.
  • Zero-clearance top-mount installation; mounting clips provided for counters up to 3" thick.
  • UL, cULus & NSF 4 listed; Made in USA and backed by a 2-year warranty.

At-a-glance specifications

Manufacturer / Model Vollrath 36646HD
Wells 2 rotated full-size, marine-grade
Total wattage 2000 W (1000 W per well)
Electrical 208-240 V • 60 Hz • 1-phase • 7.2-8.3 A
Plug NEMA 6-15P (6 ft cord)
Controls Individual thermostatic dials with power lights
Well size (each) 20" L × 12" W × 8" D
Overall dimensions 45-1/2" L × 18" W
Counter cutout 44-11/16" L × 17-1/4" W • 7/8" corner radius
Drain connection ½" NPT ball valves; plugs included
Construction 316 stainless wells • stainless exterior housing • foam insulated
Certifications UL • cULus • NSF 4 • Made in USA
Warranty 2-year parts & labor (see full policy)

Perfect for

  • Cafeterias & buffets
  • Convenience-store hot food bars
  • Compact chef stations & kiosks

Operation with water is required for even heat distribution. Designed for holding pre-heated food only – not for rethermalizing.

Looking to hold sheet pans? Add Vollrath adapter #19186 (sold separately).

Important: Drop-in units are built to order and cannot be cancelled or returned once production has begun.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, UL, Made in USA

Height

15.0in

Width

45.44in

Depth

18.0in

Shipping Weight

100.0lbs

Insulated or Non-Insulated

insulated

Style

individual pans

Controls

thermostatic controls

Drain

with drain

Construction

stainless steel construction

Pan Capacity

(2) full size (12" x 20")

Wet or Dry operation

wet

Specifications

Short Sided Hot Well, Drop-In, (2) pan, thermostatic controls, standard drains, 2000 watts, 208-240v/60/1-ph, 7.2-8.3 amps, NEMA 6-15P, turns full size pans sideways for more narrow presentation & easy reach, 18 gauge/316 marine grade stainless steel top, stainless steel exterior housing, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 45-1/2" x 18", cutout dimensions 44-11/16" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
