Vollrath  |  SKU: 3664630HD

Vollrath 3664630HD Steam Tables & Food Wells

$3,580.75
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Vollrath 3664630HD Short-Side Modular Drop-In Hot Well — 2 Pan, Marine-Grade

Thermostatic • Auto-Fill • Manifold Drain • 208-240 V

Save precious counter depth without sacrificing capacity. This Vollrath short-side hot well turns two full-size pans sideways, pulling food closer to customers for faster, easier service. Its 18-gauge 316 marine-grade stainless steel construction stands up to steam, salt and cleaning chemicals, while an automatic water fill system keeps wells at the perfect level all day long.

Key benefits

  • Narrow 18 inch footprint — ideal for tight counters or front-of-house lines.
  • Auto-fill maintains correct water level automatically, protecting elements and food quality.
  • 1" copper manifold drain with master shut-off makes end-of-day cleanup quick and sanitary.
  • Independent thermostatic controls (1000 W each) deliver precise holding temps.
  • 316 marine-grade stainless well delivers superior corrosion resistance versus 304 stainless.
  • Full-perimeter drip edge and included gasket keep condensation off the counter.
  • Thick polyurethane foam insulation improves efficiency and keeps exterior surfaces cool.
  • Ships ready to plug in — 6 ft cord with NEMA 6-15P, no hard-wiring required.
  • Made in the USA and backed by a 2-year limited warranty.

Specifications

Manufacturer / Model Vollrath 3664630HD
Install Type Top-mount, drop-in, zero-clearance
Pan Capacity (2) full-size 12" × 20" pans up to 6" deep (adapter bars suggested for fractional pans)
Well Size (each) 20" × 12" × 8" deep
Overall Dimensions 45 1⁄2" W × 18" D
Counter Cutout 44 11⁄16" W × 17 1⁄4" D, 7⁄8" corner radius
Heat / Controls Moist heat, 1000 W per well; independent thermostatic knobs & indicator lights
Auto-Fill Factory installed, connects to filtered water supply
Drain 1" copper manifold with master ball valve; 1⁄2" individual well drains; drain plug included
Electrical 2000 W total, 208-240 V / 60 Hz / 1-ph, 7.2 – 8.3 A, NEMA 6-15P
Construction 18-ga 316 stainless well & top; stainless steel exterior housing
Certifications cULus, NSF 4
Origin Made in USA

What’s in the box

  • Drop-in hot well assembly with auto-fill & manifold drain
  • Remote stainless steel control panel (4 ft tether)
  • Mounting clips for counters up to 3" thick
  • Perimeter gasket & drain plug
  • 6 ft power cord with NEMA 6-15P plug
Important: Operate with water in the well to ensure even heating. Designed for holding pre-cooked food — not for re-thermalizing. Orders for drop-in units cannot be cancelled or returned.

For complete warranty details, visit vollrathfoodservice.com.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, UL, Made in USA

Height

21.5in

Width

45.44in

Depth

18.0in

Shipping Weight

108.0lbs

Controls

thermostatic controls

Style

individual pans

Insulated or Non-Insulated

insulated

Construction

stainless steel construction

Drain

with drain

Pan Capacity

(2) full size (12" x 20")

Wet or Dry operation

wet

Specifications

Short Sided Hot Well, Drop-In, (2) pan, thermostatic controls, autofill & manifold drain, 2000 watts, 208-240v/60/1-ph, 7.2-8.3 amps, NEMA 6-15P, turns full size pans sideways for more narrow presentation & easy reach, 18 gauge/316 marine grade stainless steel top, stainless steel exterior housing, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 45-1/2" x 18", cutout dimensions 44-11/16" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
