Vollrath Short-Side 2-Pan Hot Well Drop-In | Item #3664630
Thermostatic • Auto-Fill • Manifold Drain • 208-240 VGive guests easy, front-row access to hot entrées while saving precious counter depth. This Vollrath short-side hot well turns two full-size pans sideways for a slim 18-inch profile, yet still delivers even, NSF-approved moist heat thanks to thermostatic controls and an automatic water-fill system. Built, wired and tested in the USA, it ships ready to drop into a 7⁄8"-radius cutout—no hard-wiring required.
Key benefits
- Narrow 18" front-to-back footprint keeps food within easy reach.
- Auto-fill kit maintains water level automatically—no babysitting needed.
- Manifold drain with individual well shut-offs makes daily cleanup fast.
- Precise thermostatic control (one per well) holds safe serving temperatures.
- 18 ga 18/8 stainless-steel top with full-perimeter drip edge contains spills.
- Thick polyurethane foam insulation allows zero-clearance installation & boosts efficiency.
- 8" deep stainless wells accept full-size or fractional pans up to 6" deep.
- 6 ft cord with factory-installed NEMA 6-15P plug—just drop in and power up.
- UL, CUL, and NSF listed; one-year parts & labor warranty.
- Made in Sheboygan, Wisconsin, USA.
Technical specifications
| Item number | 3664630 |
|---|---|
| Capacity | 2 full-size steam table pans (sideways orientation) |
| Controls | Independent thermostatic knobs & power indicator lights |
| Heating | 1000 W per well | 2000 W total |
| Electrical | 208-240 V / 60 Hz / 1-ph | 7.2-8.3 A | NEMA 6-15P |
| Overall dimensions (W × D) | 45 ½" × 18" |
| Cutout size (W × D) | 44 11⁄16" × 17 ¼" | 7⁄8" corner radius |
| Well size (each) | 20" × 12" × 8" deep |
| Drain | ½" welded stainless fitting with ball-valve shut-off + 1" copper manifold |
| Construction | 18 ga 18/8 stainless top & wells, galvanized steel exterior housing |
| Certifications | UL, CUL, NSF 4 |
