Vollrath  |  SKU: 3664530

Vollrath 3664530 Steam Tables & Food Wells

$4,241.10
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Short-Side Four-Pan Hot Drop-In Well with Auto-Fill & Manifold Drain

Vollrath • Item 3664530 • 120 V / 2500 W

Turn full-size pans sideways and reclaim precious counter depth. Designed for tight serving lines, this Vollrath short-side hot well delivers even, energy-efficient holding power while keeping food conveniently within reach of both staff and customers.

Why you’ll love it
  • Narrow 18 in. front-to-back footprint—perfect when space is at a premium.
  • Rotated pan presentation pulls food forward for faster, easier service.
  • Built-in auto-fill maintains the ideal water level for consistent, moist heat.
  • 1 in. copper manifold drain with master shut-off plus individual ½ in. ball valves for quick, mess-free emptying.
  • Independent infinite-range controls and power lights for each well on a remote 18/8 stainless-steel panel (4 ft tether).
  • 18/8 stainless top flange & 8 in. deep drawn wells offer exceptional durability and corrosion resistance.
  • Thick polyurethane foam insulation—on every side and between wells—locks in heat and reduces energy costs.
  • Full-perimeter drip edge with supplied gasket keeps condensation off your countertop.
  • Ships ready to use: 6 ft cord with NEMA 5-30P plug—no hard wiring required.
  • UL, cUL & NSF listed; engineered and manufactured in the USA.
Technical specifications
Capacity 4 full-size steam table pans (accepts pans up to 6 in. deep)
Controls Infinite (variable) dial for each well
Total wattage 2500 W • 625 W per well
Electrical 120 V / 60 Hz / 1-ph • 20.8 A • NEMA 5-30P
Overall dimensions 88 ¼ in. L × 18 in. D
Counter cut-out 87 ½ in. L × 17 ¼ in. D • 7/8 in. corner radius
Well interior (each) 20 in. L × 12 in. W × 8 in. D
Installation Top-mount, zero-clearance; mounting clips included for counters ≤ 3 in. thick
Construction 18/8 stainless steel, polyurethane foam insulated
Certifications UL, CUL, NSF
Important – Wet Operation Required: Fill each well with water before use to ensure even heating and maintain NSF 4 compliance.

Drop-ins are built to order and cannot be cancelled or returned. For complete warranty details, please visit vollrathfoodservice.com.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, UL, Made in USA

Height

21.5in

Width

88.56in

Depth

18.0in

Shipping Weight

177.0lbs

Controls

infinite controls

Style

individual pans

Construction

stainless steel construction

Insulated or Non-Insulated

insulated

Pan Capacity

(4) full size (12" x 20")

Drain

with drain

Wet or Dry operation

wet

Specifications

Short Sided Hot Well, Drop-In, (4) pan, infinite controls, autofill & manifold drain, 2500 watts, 120v/60/1-ph, 20.8 amps, NEMA 5-30P, turns full size pans sideways for more narrow presentation & easy reach, 18/8 stainless steel, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 88-1/4" x 18", cutout dimensions 87-1/2" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
