Vollrath  |  SKU: 36645

Vollrath 36645 Steam Tables & Food Wells

$2,973.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Catalog page Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Vollrath Short-Side 4-Well Hot Drop-In

Compact sideways presentation • Infinite controls • 120 V plug-in convenience

Perfect for buffet lines with limited counter depth, this Vollrath short-side hot well turns four full-size pans sideways so guests can reach food easily while you keep a clean, narrow profile. Plug it into a standard 120 V/20 A circuit, add water and you’re ready for NSF-compliant hot holding—all without hard-wiring.

Key Features
  • Side-facing design reduces footprint to just 18 inches front-to-back.
  • Four independent infinite controls with power lights on a stainless remote panel (4 ft tether).
  • 18/8 (300-series) stainless-steel top flange & drawn wells for superior corrosion resistance.
  • Thick polyurethane foam insulation on all non-exposed sides—including between wells.
  • Full-perimeter drip edge with included gasket helps keep countertops dry.
  • ½ in. standard drains with individual ball valves; drain plug supplied.
  • 6 ft cord and NEMA 5-30P straight-blade plug—no electrician required.
  • Accepts full-size or fractional pans up to 6 in. deep (adapter bars recommended for fractional pans).
  • Zero-clearance installation and 7⁄8 in. corner radius simplify drop-in cutting.
  • UL, cULus & NSF listed; proudly Made in the USA.
Specifications
Model / Item # 36645 (standard drain, infinite controls)
Number of wells 4 full-size (sideways)
Power per well / Total 625 W × 4 = 2,500 W
Electrical 120 V • 60 Hz • 1-phase • 20.8 A
Plug NEMA 5-30P (6 ft cord)
Controls Infinite (one per well) with indicator lights
Material 18/8 stainless steel well & flange
Insulation High-density polyurethane foam on all sides
Overall dimensions (L × W) 88 ¼ in. × 18 in. (224.2 cm × 45.7 cm)
Cut-out dimensions 87 ½ in. × 17 ¼ in. (222.3 cm × 43.8 cm)
Corner radius 7⁄8 in. (2.2 cm)
Individual well size 20 in. × 12 in. × 8 in. deep
Certifications UL, cULus, NSF
Country of origin United States
Important: For even heat distribution and to meet NSF 4 performance standards, operate the wells with water at all times.

For complete warranty terms, visit vollrathfoodservice.com. Orders for drop-ins cannot be canceled or returned.

Features & Specs

Manufacturer

Vollrath

Certifications

NSF, UL, Made in USA

Height

15.0in

Width

88.56in

Depth

18.0in

Shipping Weight

172.0lbs

Controls

infinite controls

Style

individual pans

Construction

stainless steel construction

Insulated or Non-Insulated

insulated

Pan Capacity

(4) full size (12" x 20")

Drain

with drain

Wet or Dry operation

wet

Specifications

Short Sided Hot Well, Drop-In, (4) pan, infinite controls, standard drains, 2500 watts, 120v/60/1-ph, 20.8 amps, NEMA 5-30P, turns full size pans sideways for more narrow presentation & easy reach, 18/8 stainless steel, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 88-1/4" x 18", cutout dimensions 87-1/2" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
