Vollrath 3664430 Steam Tables & Food Wells
Description
Vollrath Short-Side Hot Drop-In – 4-Pan, Auto-Fill Manifold Drain
Model 3664430 • 120 V • 2500 W • Thermostatic ControlsPerfect for cafés, kiosks, and serving lines where every inch counts, this Vollrath short-side hot well turns four full-size pans sideways to give you a slim 18-inch profile without sacrificing capacity or accessibility. Individual thermostatic controls, automatic water fill, and an integrated manifold drain make day-to-day operation effortless and efficient.
Key features
- Space-saving design — full-size 12 × 20 in pans load sideways for a narrow, easy-reach presentation.
- Thermostatic, per-well temperature control with dedicated power indicators.
- Auto-fill system maintains proper water level for consistent, moist heat.
- 1 in copper manifold drain with master shut-off; ½ in ball-valve drains on each well.
- 18/8 (300-series) stainless-steel top flange & drawn wells with full-perimeter drip edge.
- 8 in deep, fully insulated wells accept pans up to 6 in deep; adapter bars recommended for fractional pans.
- Remote stainless-steel control panel on a 4 ft (121.9 cm) tether for flexible mounting.
- 6 ft (1.8 m) factory-wired cord with NEMA 5-30P — no hard-wiring required.
- Zero-clearance, top-mount installation; gasket & mounting clips for counters up to 3 in (7.6 cm) thick included.
- UL, cUL-US & NSF listed; proudly Made in the USA.
At-a-glance specs
| Model | 3664430 |
|---|---|
| Pans Held | (4) full-size 12 × 20 in pans, sideways orientation |
| Control Type | Individual thermostatic knobs |
| Electrical | 2500 W • 120 V / 60 Hz / 1-ph • 20.8 A |
| Plug | NEMA 5-30P (6 ft cord factory installed) |
| Overall Dimensions (W × D) | 88 1/4 × 18 in (224.2 × 45.7 cm) |
| Cut-out Dimensions (W × D) | 87 1/2 × 17 1/4 in (222.3 × 43.8 cm) |
| Corner Radius | 7/8 in (2.2 cm) |
| Well Interior (each) | 20 × 12 in (50.8 × 30.5 cm) • 8 in (20.3 cm) deep |
| Drain | 1 in copper manifold with master valve; ½ in individual drains; plug included |
| Operating Mode | Wet (water required for even heating) |
| Listings | UL • cUL-US • NSF |
| Country of Origin | USA |
What’s included
- Remote control panel with mounting screws
- Mounting gasket & clips
- Drain plug
- Factory-installed power cord & plug
Looking to hold sheet pans? Add Vollrath adapter bar #19186 (sold separately).
For complete warranty details, visit vollrathfoodservice.com.
